1SS367TPH3F

Description
Schottky Diodes & Rectifiers 0.1A 10V Schottky Small Sig Diode
Categorysemiconductor    Discrete semiconductor
File Size216KB,4 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Environmental Compliance
Download Datasheet Parametric View All

1SS367TPH3F Online Shopping

Suppliers Part Number Price MOQ In stock
1SS367TPH3F - - View Buy Now

1SS367TPH3F Overview

Schottky Diodes & Rectifiers 0.1A 10V Schottky Small Sig Diode

1SS367TPH3F Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerToshiba Semiconductor
Product CategorySchottky Diodes & Rectifiers
RoHSDetails
ProductSchottky Diodes
Mounting StyleSMD/SMT
Package / CaseSOD-323-2
If - Forward Current100 mA
Vrrm - Repetitive Reverse Voltage15 V
Vf - Forward Voltage0.23 V
Ifsm - Forward Surge Current1 A
ConfigurationSingle
TechnologySi
Ir - Reverse Current20 uA
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 100 C
PackagingCut Tape
PackagingMouseReel
PackagingReel
Operating Temperature Range- 40 C to + 100 C
Pd - Power Dissipation200 mW
Factory Pack Quantity3000
Unit Weight0.000363 oz
1SS367
TOSHIBA Diode
Silicon Epitaxial Schottky Barrier Type
1SS367
High Speed Switching Application
Small package
Low forward voltage: V
F
= 0.23V (typ.) @I
F
= 5mA
Unit: mm
Absolute Maximum Ratings
(Ta = 25°C)
Characteristic
Maximum (peak) reverse voltage
Reverse voltage
Maximum (peak) forward current
Average forward current
Surge current (10ms)
Power dissipation
Junction temperature
Storage temperature
Operating temperature range
Symbol
V
RM
V
R
I
FM
I
O
I
FSM
P
*
T
j
T
stg
T
opr
Rating
15
10
200
100
1
200
125
−55~125
−40~100
Unit
V
V
mA
mA
A
mW
°C
°C
°C
Note: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are
within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
*
Mounted on a glass epoxy circuit board of 20 × 20 mm
Pad dimension of 4 × 4 mm.
JEDEC
JEITA
TOSHIBA
1-1E1A
Weight: 0.004g (typ.)
Electrical Characteristics
(Ta = 25°C)
Characteristic
Symbol
V
F (1)
Forward voltage
V
F (2)
V
F (3)
Reverse current
Total capacitance
I
R
C
T
Test
Circuit
Test Condition
I
F
= 1mA
I
F
= 5mA
I
F
= 100mA
V
R
= 10V
V
R
= 0, f = 1MHz
Min
Typ.
0.18
0.23
0.35
20
Max
0.30
0.50
20
40
μA
pF
V
Unit
Equivalent Circuit
(Top View)
Marking
1
2007-11-01
