MIC5316-F4CYMT-TR

Description
LDO Regulator Pos 1.5V1.2V1V 0.3A/0.3A/0.3A 12-Pin Thin MLF EP T/R
File Size372KB，14 Pages
ManufacturerMicrochip
Websitehttps://www.microchip.com
Environmental Compliance
Download Datasheet Parametric Compare View All

MIC5316-F4CYMT-TR Online Shopping

Suppliers Part Number Price MOQ In stock
MIC5316-F4CYMT-TR - - View Buy Now

MIC5316-F4CYMT-TR Overview

LDO Regulator Pos 1.5V1.2V1V 0.3A/0.3A/0.3A 12-Pin Thin MLF EP T/R

MIC5316-F4CYMT-TR Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
HTS8542.39.00.01
TypeLDO
Number of Outputs2
PolarityPositive
Accuracy (%)±1
Output TypeFixed
Output Voltage (V)1.5|1|1.2
Maximum Output Current (A)0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3
Minimum Input Voltage (V)1.7
Maximum Input Voltage (V)5.5
Maximum Dropout Voltage @ Current (V)0.1@150mA|0.2@300mA
Line Regulation0.02%/V(Typ)
Load Regulation0.4%(Typ)
Typical Ground Current @ Full Load (mA)0.007
Junction to Ambient70°C/W
Special FeaturesCurrent Limit|Thermal Shutdown Protection
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)125
PackagingTape and Reel
Supplier PackageThin MLF EP
Pin Count12
Standard Package NameQFN
MountingSurface Mount
Package Height0.55(Max)
Package Length2.5
Package Width2.5
PCB changed12
Lead ShapeNo Lead

Preview

Download Datasheet
MIC5316
Low Voltage Dual 300mA LDO with
Power on Reset and Voltage Select
General Description
Features
The MIC5316 is a high performance, dual low input
•
300mA output current for each LDO
voltage, low dropout regulator with Power On Reset (POR)
•
Dual low voltage regulator inputs: 1.7V to 5.5V
and voltage select. Major features include two 300mA
•
Low output voltage range: 0.8V to 2.0V
LDOs, input voltage down to 1.7V, ultra low drop out of
•
Ultra-low dropout voltage of 85mV @ 300mA
85mV at full load, Power on Reset, and voltage select.
•
Voltage select function
Each LDO has its own low voltage input for system
flexibility. The low input voltages and low drop out
•
Power On Reset output with adjustable delay
operation provides high efficiency by reducing the input to
•
Stable with 1µF ceramic output capacitors
output voltage step which minimizes the regulator power
•
Very fast transient response
loss. Voltage select is incorporated into the second output,
•
Thermal shutdown and current limit protection
which reduces the output voltage to further save power
while in stand-by mode. An adjustable delay time POR
•
Tiny 12-pin 2.5mm x 2.5mm Thin MLF
®
package
output is provided for the second regulator for design
flexibility.
Applications
Ideal for battery operated applications; the MIC5316 offers
1% accuracy and low ground current to increase light load
•
Mobile Phones
efficiency. The MIC5316 can also be put into a zero-off-
•
GPS and Navigation Devices
mode current state, drawing virtually no current when
•
Portable Media Players
disabled.
•
Digital still and video cameras
The MIC5316 is available in fixed output voltages in the
•
PDAs
12-pin 2.5mm x 2.5mm Thin MLF
®
leadless package.
•
Portable electronics
Data sheets and support documentation can be found on
Micrel’s web site at: www.micrel.com.
___________________________________________________________________________________________________________
Typical Application
VI/O
MIC5316-xxyYMT
VBAT
MIC23031-1.8YMT
DC-to-DC
Converter
VIN1
VIN2
VBIAS
CIN
1µF
CBIAS
1µF
/VSC2
EN1
EN2
GND
VOUT1
VOUT2
POR2
CBYP
CSET2
10nF
1µF
1µF
VCORE1
VCORE2
µProcessor
MLF and
MicroLeadFrame
are registered trademarks of Amkor Technology, Inc.
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (
408
) 944-0800 • fax + 1 (408) 474-1000 • http://www.micrel.com
July 2008
M9999-070208-A
