1N4001
THRU
1N4 007
SILICON RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 1.0 Ampere
FEATURES
*
*
*
*
Low cost
Low leakage
Low forward voltage drop
High current capability
MECHANICAL DATA
*
*
*
*
*
Case: Molded plastic
Epoxy: Device has UL flammability classification 94V-O
Lead: MIL-STD-202E method 208C guaranteed
Mounting position: Any
Weight: 0.33 gram
1.0 (25.4)
MIN.
.034 (0.9)
DIA.
.028 (0.7)
.205 (5.2)
.166 (4.2)
.107 (2.7)
.080 (2.0)
DIA.
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
1.0 (25.4)
MIN.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS
(At T
A
= 25 C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
o
at T
A
= 75 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Current Squared Time
Typical Junction Capacitance (Note)
Typical Thermal Resistance
Operating and Storage Temperature Range
ELECTRICAL CHARACTERISTICS
(At T
A
= 25 C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 1.0A DC
@T
A
= 25
o
C
Maximum DC Reverse Current
o
at Rated DC Blocking Voltage
@T
A
= 100 C
Maximum Full Load Reverse Current Average, Full Cycle
.375” (9.5mm) lead length at T
L
= 75
o
C
NOTES : Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
SYMBOL
V
F
I
R
1N4001 1N4002
1N4003 1N4004
1.0
0.2
25
20
1N4005
1N4006
1N4007
UNITS
Volts
uAmps
uAmps
2017-04
REV:C
o
o
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
I
2
T
C
J
R
JA
T
J
, T
STG
1N4001 1N4002
50
35
50
100
70
100
1N4003 1N4004
200
140
200
400
280
400
1.0
30
3.74
15
1N4005
600
420
600
1N4006
800
560
800
1N4007
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
2
AS
pF
0
50
-55 to + 150
C/ W
0
C
RATING AND CHARACTERISTIC CURVES ( 1N4001 THRU 1N4007 )
FIG. 1 - TYPICAL FORWARD CURRENT
DERATING CURVE
1.0
AVERAGE FORWARD RECTIFIED
CURRENT, (A)
INSTANTANEOUS FORWARD
CURRENT, (A)
FIG. 2 - MAXIMUM INSTANTANEOUS FORWARD
CHARACTERISTICS
20
10
4
2
1.0
.4
.2
.1
.04
.02
.01
.6
INSTANTANEOUS REVERSE CURRENT, (uA)
TJ = 25
Pulse Width=300uS
1% Duty Cycle
.8
.6
.4
.2
Single Phase
Half Wave 60Hz
Resistive or
Inductive Load
0
0
25 50
75 100 125 150 175
AMBIENT TEMPERATURE, ( )
.8
1.0
1.2
1.4 1.5
INSTANTANEOUS FORWARD VOLTAGE, (V)
FIG. 4 - MAXIMUM REVERSE CHARACTERISTICS
PEAK FORWARD SURGE
CURRENT, (A)
FIG. 3 - MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
50
40
30
20
10
0
8.3ms Single Half Sine-Wave
(JEDED Method)
100
10
TJ = 100
1
.2
TJ = 25
1
2
4 6 8 10 20 40 60 80 100
NUMBER OF CYCLES AT 60Hz
.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
JUNCTION CAPACITANCE, (pF)
200
100
60
40
20
10
6
4
2
1
.1
.2
.4
1.0 2 4
10 20 40 100
REVERSE VOLTAGE, ( V )
TJ = 25
RECTRON
AXIAL LEAD TAPING SPECIFICATIONS
FOR RECTIFIERS
Axial lead devices are packed in accordance with EIA standard RS-296-D and specifications given below.
COMPNENT
OUTLINE
T-1
R-1
A-405
A-405
DO-41
DO-41
DO-15
R-3
DO-201AD
R-6
COMPONENT
PITCH A
0.5mm (.020")
5.0mm
5.0mm
5.0mm
5.0mm
5.0mm
5.0mm
5.0mm
5.0mm
10.0mm
10.0mm
INNER TAPE
PITCH B
0.5mm (.020")
1.5mm (.059")
26.0mm
26.0mm
26.0mm
52.4mm
26.0mm
52.4mm
52.4mm
52.4mm
52.4mm
52.4mm
CUMULATIVE PITCH
TOLERANCE
2.0mm/20pitch
2.0mm/20pitch
2.0mm/20pitch
2.0mm/20pitch
2.0mm/20pitch
2.0mm/10pitch
2.0mm/10pitch
2.0mm/10pitch
2.0mm/10pitch
2.0mm/10pitch
Z
A
90 5
O
O
D
O
E
W
L
1
D
1
B
L
2
D
E
T
Fig.: Configuration of AXIAL LEAD TAPING
ITEM
Component alignment
Tape width
Exposed adhesive
Body eccentricity
Reel outside diameter
Reel inner diameter
Feed hole diameter
Reel width
Notes :
SYMBOL
Z
T
E
IL
1
-L
2
I
D
D
1
D
O
W
SPECIFICATIONS (mm)
1.2 Max.
6.0 0.4
0.8 Max.
1.0 Max.
330.0
85.7 0.3
30.5 0.4
79.0 1.0
SPECIFICATIONS (inch)
0.047 Max.
0.236 0.016
0.032 Max.
0.039 Max.
13.0
3.374 0.012
1.201 0.016
3.110 0.039
1.Each component lead shall be sandwiched between tapes for a minimum of 3.2mm (0.126").
2.The reel width "W" for 26mm taping is 50.0 1.0mm (1.97" 0.040").
PACKAGING OF DIODE AND BRIDGE RECTIFIERS
BULK PACK
PACKAGE
DO-41
eg(TYPE):1N4007-B
PACKING CODE
-B
EA PER BOX INNER BOX SIZE
(mm)
1,000
194*75*21
CARTON SIZE EA PER CARTON
(mm)
415*220*255
50,000
GROSS
WEIGHT(Kg)
16.2
REEL PACK
PACKAGE
DO-41
PACKING
EA PER EA PER COMPONENT TAPE SPACE REEL DIA CARTON SIZE EA PER
GROSS
SPACE
INNER
REEL
CARTON WEIGHT(Kg)
CODE
(mm)
(mm)
(mm)
(mm)
BOX
-T
5,000
5,000
5.0
52
330
355*350*335
20,000
10.49
eg(TYPE):1N4007-T
AMMO PACK
PACKAGE
DO-41
DO-41
PACKING
CODE
-F
-E
REEL
( EA )
3,000
3,000
COMPONENT TAPE SPACE
SPACE(mm)
(mm)
5.0
5.0
52
26
BOX SIZE
(mm)
CARTON
SIZE(mm)
CARTON
( EA )
30,000
42,000
GROSS
WEIGHT (Kg)
13.0
12.41
255*73*100 400*268*225
256*48*94
365*270*217
eg(TYPE):1N4007-F,1N4007-E
RECTRON
Attachment information about 1N400X
1. Internal Circuit
Anode
Cathode
2. Marking on the body
Plant - code
V X X
Rectron Logo
Part No.
Month - code
Cathode Band
Year - code
1N 4 0 0 X
Voltage-code
1-------50V
2-------100V
3-------200V
4-------400V
5-------600V
6-------800V
7-------1000V
3. The net weight
330mg / pcs
4. Taping packaging specification
4.1 All polarized components must be oriented in one direction.
4.2 For diode, at least one side of the cathode lead tape should be
red, and anode lead tape should be white.
4.3A
minimum 300 mm (12”) leader shall be provided at each end
of the reel.
4.4 Staples shall not be used for splicing. Splice length shall be 4.0
inches minimum and shall not be misaligned more than 0.8mm.
