EGP30A - EGP30K 3.0 Ampere Glass Passivated High Efficiency Rectifiers
July 2007
EGP30A - EGP30K
3.0 Ampere Glass Passivated High Efficiency Rectifiers
Features
• Glass passivated cavity-free junction
• High surge current capability
• Low leakage current
• Superfast recovery time for high efficiency
• Low forward voltage, high current capability
DO-201AD Glass case
COLOR BAND DENOTES CATHODE
Absolute Maximum Ratings*
Symbol
I
O
i
f(surge)
T
a
= 25°C unless otherwise noted
Parameter
Average Rectified Current
.375 " lead length @ T
L
= 55°C
Peak Forward Surge Current
8.3 ms single half-sine-wave
Superimposed on rated load (JEDEC method)
Total Device Dissipation
Derate above 25°C
Thermal Resistance, Junction to Ambient
Thermal Resistance, Junction to Lead
Junction and Storage Temperature Range
Value
3.0
Units
A
125
6.25
50
20
8.5
-65 ~ 150
A
W
mW°C
°C/W
°C/W
°C
P
D
R
θJA
R
θJL
T
J
, T
STG
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
