53547-2 Product Details
Live Product Chat
Product Photo
Radiation Resistant/Pre-Insulated Terminals & Splices
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
53547-2
T E I nternal N umber: 5 3 5 4 7 - 2
Product Highlights:
l
Splice
l
2 C lass
l
Wire Range = 0.20-0.60² [24-20] mm [AWG]
l
Wire Range = 320 - 1290 C MA
l
Body Style = PIDG
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Splice
l
Body Style
= PIDG
l
Wire Insulation Diameter (mm [in])
= 2.54 [0.100]
l
Finish
= Tin-Lead
l
Splice Type = Butt
l
C olor C ode = White
l
Body Material = C opper
l
Insulation = Yes
Body Related Features:
l
Wire Range (mm [AWG])
= 0.20-0.60² [24-20]
l
Wire Range (C MA)
= 320 – 1,290
l
Barrel I.D. Min. (mm [in])
= 1.09 [0.043]
l
Insulation Sleeve C olor = Natural
l
Insulation Sleeve Material = PVF2
l
Insulation Support Sleeve Material = C opper
Contact Related Features:
l
C lass
= 2
Industry Standards:
l
Government/Industry Qualification = Yes
l
Government/Industry Part Number = M7928/6-2
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
Packaging Related Features:
l
Packaging Method
= Tape Mounted
Other:
l
Brand = AMP
