1437568-2: DescriptionPushbutton Switch, PUSHBUTTON SWITCH, SPST, MOMENTARY, 0.1A, 50VDC, PANEL MOUNT-THREADED; CategoryMechanical and electronic products switch; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

1437568-2 Overview

Pushbutton Switch, PUSHBUTTON SWITCH, SPST, MOMENTARY, 0.1A, 50VDC, PANEL MOUNT-THREADED

1437568-2 Parametric

Parameter Name	Attribute value
Brand Name	Alcoswitch
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
ECCN code	EAR99
Actuator type	EXTENDED TYPE
Maximum contact current (DC)	0.1 A
Contact (DC) maximum rated R load	.1A@50VDC
Maximum contact voltage (DC)	50 V
Manufacturer's serial number	1437568
Installation features	PANEL MOUNT-THREADED
Maximum operating force	2.22 N
method of packing	BULK
surface mount	NO
Switch action	MOMENTARY
switch function	SPST
Switch type	PUSHBUTTON SWITCH
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se arch by Ke yword or Part #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Switches

Product Feature Selector

> Product Details

MSPM101CP Product Details

Live Product Chat

Pushbutton Switches

Not EU R oHS or ELV C om pliant

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

MSPM101CP

(1437568-2)

T E I nternal N umber: 1 4 3 7 5 6 8 - 2

Product Highlights:

Switch - Mechanical

Not Tactile

Single Pole - Single Throw C onfiguration (Pole-Throw)

C ontact Rating = 1.0 VA optimum [100mA max., 50

VDC max.]

Process Sealed

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

ALC OSWITC H PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Switch - Mechanical

Tactile = No

C onfiguration (Pole-Throw) = Single Pole - Single Throw

Mount Angle = Vertical

Termination Type = Pins

Actuator Style = C ap - Supplied

C omment = Red cap supplied.

Electrical Characteristics:

C ontact Rating = 1.0 VA optimum [100mA max., 50 VDC max.]

Body Related Features:

Series

= MSPM

Mount Style = Panel

Actuator Length (mm [in]) = 12.19 [0.480]

Actuator Profile = Extended

Bushing Diameter = 1/4-40

C ase Material = Steel

Actuator Material = Polyamide

Contact Related Features:

C ontact Plating = Gold

Housing Related Features:

Process Sealed = Yes

Low Profile = No

Bushing Style = Threaded

Configuration Related Features:

Operating Function = Push C losed, Pull Open

Ganged = No

ESD Grounding Terminal = Without

Actuator Force (g [oz]) = 141.80 – 226.80 [5.000 – 8.000]

Number of Actuators = Single

Illuminated = No

Dust Proof = No

Support Bracket = Without

Snap Action = Without

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Hand solderable with tin/lead solder

Conditions for Usage:

Temperature Rating = Standard

Packaging Related Features:

Packaging Method = Loose Piece

Other:

Brand = Alcoswitch

Additional Information:

Product Line Information
