1745072 Overview

Fixed Terminal Blocks ZFKKDSA1,5C-5,0-4 BK

1745072 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	PHOENIX CONTACT
Product Category	Fixed Terminal Blocks
Shipping Restrictions	Mouser does not presently sell this product in your region.
Number of Positions	4 Position
Pitch	5 mm
Connection Method	Spring Cage
Product	Fixed Terminal Blocks
Factory Pack Quantity	50
Unit Weight	0.384098 oz

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1745072

PCB terminal block - ZFKKDSA 1,5C-5,0- 4 BK - 1745072

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 16 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 4,

Connection method: Spring-cage connection, Mounting: Wave soldering, Conductor/PCB connection

direction: 45 °, Color: black

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356307369

85369010

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Length

Pitch

Dimension a

Constructional height

Length of the solder pin

Pin dimensions

Hole diameter

21 mm

5.00 mm

15 mm

26 mm

3.7 mm

0,7 x 0,7 mm

1.1 mm

General

Range of articles

Insulating material group

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

Nominal cross section

ZFKKDS(A) 1,5C

4 kV

250 V

400 V

630 V

EN-VDE

16 A

1.5 mm²

11/14/2016 Page 1 / 2
