SiT8003AC-14-18E-16.00000T

Description
Standard Clock Oscillators 16MHz 1.8Volts OE 100ppm -20C +70C
CategoryPassive components
File Size77KB,3 Pages
ManufacturerSiTime
Environmental Compliance
Download Datasheet Parametric View All

SiT8003AC-14-18E-16.00000T Overview

Standard Clock Oscillators 16MHz 1.8Volts OE 100ppm -20C +70C

SiT8003AC-14-18E-16.00000T Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerSiTime
Product CategoryStandard Clock Oscillators
RoHSDetails
Package / CaseQFN-4
Length2.5 mm
Width2 mm
PackagingCut Tape
PackagingReel
Factory Pack Quantity3000
Unit Weight0.000353 oz
SiT8003
1 - 110 MHz
Features
Preliminary Information
Low Power Programmable Oscillator
The world’s lowest power programmable oscillator with 3.0 mA typical active current
1-110 MHz frequency range. Contact SiTime for frequencies between 80 MHz - 110 MHz
High frequency stability of ±25 PPM, ±30 PPM, ±50 PPM, ±100 PPM
Extremely fast start-up time of 3 ms
Typical RMS period jitter of <6 ps
Programmable standby or output enable modes
Available in four industry standard packages: 2.5 x 2.0, 3.2 x 2.5, 5.0 x 3.2, 7.0 x 5.0 mm
Outstanding mechanical robustness for portable applications
All-silicon device with outstanding reliability of 2 FIT (10x improvement over quartz-based devices),
enhancing system mean-time-to-failure (MTBF)
• Ultra short lead time
• Ideal for portable applications :portable media players, digital cameras, digital camcorders, portable
navigation device, handheld gaming, cell phone and other handheld applications.
• Ideal for high-speed serial protocols such as: USB 1.1, USB 2.0, SATA, SAS, Fiber Channel,
Firewire, Ethernet, PCI Express, etc
Specifications
Parameter
Output Frequency Range
Frequency Tolerance
Symbol
f
F_tol
Min.
1
-25
-30
-50
-100
Aging
Storage Temperature Range
Operating Temperature Range
Supply Voltage
Ag
T_use
Vdd
–1.0
-55
-20
-40
1.71
2.25
2.52
2.97
Typ.
1.8
2.5
2.8
3.3
3.0
3.5
3
7
50
50
1
Max.
110
+25
+30
+50
+100
1.0
+125
+70
+85
1.89
2.75
3.08
3.63
3.5
4.0
10
10
55
60
2
Unit
MHz
PPM
PPM
PPM
PPM
PPM
°
C
°
C
°
C
V
V
V
V
mA
mA
µA
µA
%
%
ns
Vdd
1st year at 25°
C
Extended Commercial
Industrial
Condition
Contact SiTime for frequencies between 80 MHz - 110 MHz
Inclusive of: Initial tolerance, operating temperature, rated power,
supply voltage change, load change, aging (1st yr @25°C), shock
and vibration.
Contact SiTime for ±25 PPM support in 1.8 V.
Current Consumption
Standby Current
Idd
I_std
45
40
90%
No load condition, f = 20 MHz, Vdd = 1.8 V
No load condition, f = 20 MHz, Vdd = 2.5 V, 2.8 V or 3.3 V
Output is Weakly Pulled Down, ST = GND, Vdd = 1.8 V
Output is Weakly Pulled Down, ST = GND, Vdd = 2.5 V, 2.8V or
3.3 V
All Vdds. f <= 70 MHz
All Vdds. f > 70 MHz
10% - 90% Vdd level, 15pf load
IOH = -4 mA (Vdd = 3.3 V)
IOH = -3 mA (Vdd = 2.8 V and Vdd = 2.5 V)
IOH = -2 mA (Vdd = 1.8 V)
IOL = 4 mA (Vdd = 3.3 V)
IOL = 3 mA (Vdd = 2.8 V and Vdd = 2.5 V)
IOL = 2 mA (Vdd = 1.8 V)
Maximum frequency and supply voltage. Contact SiTime for
higher output load strength option
Pin 1, OE or ST
Pin 1, OE or ST
Measured from the time Vdd reaches its rated minimum value
f = 48 MHz, Vdd = 1.8 V
f = 48 MHz, Vdd = 2.5 V, 2.8 V or 3.3 V
f = 62.5 MHz, Integration bandwidth = 1.875 MHz to 20 MHz
f = 75 MHz, Integration bandwidth = 900 kHz to 7.5 MHz
Duty Cycle
Rise/Fall Time
Output Voltage High
DC
Tr, Tf
VOH
Output Voltage Low
VOL
10%
Vdd
Output Load
Input Voltage High
Input Voltage Low
Input Current
Startup Time
RMS Period Jitter
RMS Phase Jitter (random)
Ld
VIH
VIL
I_in
T_osc
T_jitt
T_phj
70%
-
-
1.60
1.00
15
-
30%
10
3
6
4
-
-
pF
Vdd
Vdd
µA
ms
ps
ps
ps
ps
SiTime Corporation
Rev. 1.3
990 Almanor Avenue
Sunnyvale, CA 94085
(408) 328-4400
www.sitime.com
Revised March 25, 2009
