MIL-DTL-83513
Micro-D
500-017 & 500-037
Micro-D Metal Protective Cover
Choose Metal Protective Covers
for
full environmental protection.
Silicone Rubber gasket
provides a
watertight seal.
Use with M83513 Type Metal Shell
Micro-D Connectors
MATERIALs & FINIsHEs
Shell
Gasket
Hardware
Aluminum Alloy 6061 -T6
Silicone Rubber
300 Series Stainless
Steel, Passivated
sELECT A PRoTECTIVE CoVER sTYLE
style 1
Tapped
Threads
Panel
style 2
style 3
Silicone
Gasket
(All Styles)
Use With Micro-D Connectors With
Jackposts
Not for rear panel mounted connectors.
Use With Micro-D Connectors With
Jackscrews
Use With Rear-Panel Mounted Micro-D
Connectors
HoW To oRDER sTYLE 1 AND sTYLE 2 PRoTECTIVE CoVERs
series
500-017
C
E
J
shell Finish
–
Black
Connector
size
09
15
21
25
31
37
51
51-2
67
69
100
Hardware option
sTYLE 1
Lanyard option
N
–
No Lanyard
G
–
Flexible Nylon
Rope
Lanyard
Length
Ring Terminal
ordering Code
Anodize
–
Chem Film
–
Cadmium,
Yellow
Chromate
Nickel
F
–
Wire Rope,
Fits Micro-D's With Jackposts
Cover has Jackscrews
Nylon Jacket
Length in 06
–
.125 (3.2)
01
–
.140 (3.6)
one Inch
Increments 05
–
.167 (4.2)
04
–
.197 (5.0)
Example: “6”
equals six
inches.
I.D. of Ring
Terminal
M
NF
z2
–
Electroless
–
Cadmium,
–
Gold
MB
–
Fillister Head Jackscrew
MH
–
Hex Head Jackscrew
sTYLE 2
H
–
Wire Rope,
Hi-Temp
Teflon Jacket
Olive Drab
Fits Micro-D's With Jackscrews
Cover has Tapped Female Threads
F
–
Female Threads
(sTYLE 3:
see next page)
Sample Part Number
500-017
M
25
MB
F
4
– 06
© 2011 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-30
500-017 & 500-037
Micro-D Metal Protective Cover
HoW To oRDER sTYLE 3 PRoTECTIVE CoVERs FoR REAR MouNT CoNNECToRs
Series
500-037
C
E
J
Shell Finish
–
–
–
M
NF
Z2
–
–
–
Connector
Size
Black
09
Anodize
15
21
Chem Film
25
Cadmium,
Yellow
31
Chromate
37
51
Electroless
Nickel
51-2
67
Cadmium,
Olive Drab
69
100
Gold
Panel Thickness
Option
R1
R2
R3
R4
–
–
–
–
Hardware Option
STYLE 3
Lanyard Option
N
–
No Lanyard
G
–
Flexible Nylon
Rope
.031 (0.79) Panel
.047 (1.19) Panel
.062 (1.57) Panel
.093 (2.36) Panel
Panel
Fits Micro-D's With
Jackposts
B
–
Fillister Head
H
–
Hex Head
Jackscrew
Jackscrew
F
–
Wire Rope,
Nylon Jacket
TempTeflon
Jacket
Ring Terminal
Ordering Code
06
–
.125 (3.2)
01
–
.140 (3.6)
05
–
.167 (4.2)
04
–
.197 (5.0)
Length
(In Inches)
2
- Inches
(Omit for
Standard 4-inch
Length)
H
–
Wire Rope, Hi- I.D. of Ring Terminal
Sample Part Number
500-037
J
31
R4
B
G
– 06
2
PRoTECTIVE CoVER DIMENsIoNs
style 1
style 2
style 3
A
C
B
th
Leng
D
C
E
th
Leng
A
C
B
th
Leng
RING TERMINAL
DIA.
.410 (10.4) MAX
RING TERMINAL
DIA.
.310 (7.9) MAX
F
RING TERMINAL
DIA.
.260 (6.6) MAX
#2-56 UNC THREADS SIZES 9-69
#4-40 UNC THREADS SIZE 100
#2-56 UNC THREADS SIZES 9-69
#4-40 UNC THREADS SIZE 100
#2-56 UNC THREADS SIZES 9-69
#4-40 UNC THREADS SIZE 100
For Micro-D Connectors With Jackposts For Micro-D Connectors With Jackscrews
A Max.
size
9
15
21
25
31
37
51
51-2
67
69
100
For Rear-Panel Mounted Micro-D
E Max.
Panel
Thickness
R1
R2
R3
R4
B Max.
In .
.930
1.080
1.230
1.330
1.480
1.630
1.580
1.980
2.380
1.880
2.315
C
In.
.565
.715
.865
.965
1.115
1.265
1.215
1.615
2.015
1.515
1.800
D Max.
mm.
14.35
18.16
21.97
24.51
28.32
32.13
30.86
41.02
51.18
38.48
45.72
F
In.
.126
.110
.095
.064
In.
.453
.453
.453
.453
.453
.453
.496
.453
.453
.496
.539
mm.
11.5
11.5
11.5
11.5
11.5
11.5
12.6
11.5
11.5
12.6
13.7
mm.
23.6
27.4
31.2
33.8
37.6
41.4
40.1
50.3
60.5
47.8
58.8
In.
.380
.380
.380
.380
.380
.380
.420
.380
.380
.420
.470
mm.
9.65
9.65
9.65
9.65
9.65
9.65
10.67
9.65
9.65
10.67
11.94
In.
.795
.945
1.095
1.195
1.345
1.495
1.445
1.845
2.245
1.745
2.180
mm.
20.19
24.00
27.81
30.35
34.16
37.97
36.70
46.86
57.02
44.32
55.37
mm.
3.2
2.8
2.4
1.6
© 2011 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-31
REV 12 MAR 09
MIL-DTL-83513
Micro-D
