PART NUMBER DATA
J
CIRCUITS
2
3
4
5
6
7
8
9
10
11
12
I
PART
NUMBER
391002002
391002003
391002004
391002005
391002006
391002007
391002008
391002009
391002010
391002011
391002012
ENGINEERING
NUMBER
M800-02-02-5-M1
M800-02-03-5-M1
M800-02-04-5-M1
M800-02-05-5-M1
M800-02-06-5-M1
M800-02-07-5-M1
M800-02-08-5-M1
M800-02-09-5-M1
M800-02-10-5-M1
M800-02-11-5-M1
M800-02-12-5-M1
A
A IN mm
B IN mm
.394
.787
1.181
1.575
1.969
2.362
2.756
3.150
3.543
3.937
4.331
10.00
20.00
30.00
40.00
50.00
60.00
70.00
80.00
90.00
100.00
110.00
J
COLOR
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
.67
1.06
1.46
1.85
2.24
2.64
3.03
3.43
3.82
4.21
4.61
17.0
27.0
37.0
47.0
57.0
67.0
77.0
87.0
97.0
107.0
117.0
B
.394
I
.74
H
REF. LAST 2 DIGITS OF PART NUMBER EQUAL CIRCUIT COUNT
H
G
NOTE: IF THIS PRODUCT IS STORED IN AN
ENVIRONMENT WITH A RELATIVE HUMIDITY
OF LESS THAN 50%, MOISTURE MUST BE
ADDED. REFER TO TECHNICAL ADVISORY
AS 45499-001 FOR INSTRUCTIONS.
.394
C
.284
.23
A
C
G
.82
.31
.51
F
F
D
.49
E
V
D E
V
D E
V
D E
B
E
3910020
600V 30A
D
3910020
600V 30A
CONTACT FACTORY FOR OPTIONAL COLORS
D
SPECIFICATIONS:
1.Material:
(A) Screw: Steel, Zinc plated
(B) Body: PA66 UL94 V-0
(C) Cage: Brass, Nickel plated
(D) Terminal: Stainless Steel
2.Rating: 600V, 30amps
3.Wire range: 18-10 AWG
4.Max torque: 7.0 in lbs.
5.Dielectric voltage withstand: DC 3000V for 1 minute.
DESCRIPTION
C
C
B
GENERAL TOLERANCES
(UNLESS SPECIFIED)
DIMENSION STYLE
SCALE
DESIGN UNITS
IN/MM
DRAWN BY
DATE
TITLE
CHECKED BY
DATE
---
METRIC
THIRD ANGLE
PROJECTION
B
7.Rated Impulse Voltage: 4000V, Plus and Minus 5 times each
8.Strip Length: .24 in. (6.0mm)
=
0
C
mm
4 PLACES
3 PLACES
2 PLACES
1 PLACE
---
---
---
---
---
INCH
---
---
---
---
=
0
APPROVED BY
DATE
molex
A
11.All dims. shown are for reference only
C1
13
12
11
10
9
8
REV
TERMINAL STRIP 10MM
HIGH PROFILE 600V
----
MOLEX INCORPORATED
SHEET NO.
DRAFT WHERE
APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
7
6
5
MATERIAL NO.
DOCUMENT NO.
SEE CHART
SIZE
A
SD-39100-013
3
2
1
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX
INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
4
