74LCX244 — Low Voltage Buffer/Line Driver with 5V Tolerant Inputs and Outputs
December 2013
74LCX244
Low Voltage Buffer/Line Driver with 5V Tolerant
Inputs and Outputs
Features
■
5V tolerant inputs and outputs
■
2.3V to 3.6V V
CC
specifications provided
■
6.5ns t
PD
max. (V
CC
=
3.3V), 10µA I
CC
max.
■
Power down high impedance inputs and outputs
■
Supports live insertion/withdrawal
(1)
■
±24mA output drive (V
CC
=
3.0V)
■
Implements
proprietary
noise/EMI reduction circuitry
■
Latch-up performance exceeds 500mA
■
ESD performance:
General Description
The LCX244 contains eight non-inverting buffers with
3-STATE outputs. The device may be employed as a
memory address driver, clock driver and bus-oriented
transmitter/receiver. The LCX244 is designed for low
voltage (2.5V or 3.3V) V
CC
applications with capability of
interfacing to a 5V signal environment.
The LCX244 is fabricated with an advanced CMOS tech-
nology to achieve high speed operation while maintain-
ing CMOS low power dissipation.
– Human body model
>
2000V
– Machine model
>
200V
■
Leadless DQFN package
Note:
1. To ensure the high-impedance state during power up
or down, OE should be tied to V
CC
through a pull-up
resistor: the minimum value or the resistor is
determined by the current-sourcing capability of the
driver.
Ordering Information
Order Number
74LCX244WM
74LCX244SJ
74LCX244BQX
(2)
74LCX244MSA
74LCX244MTC
Package
Number
M20B
M20D
MLP20B
MSA20
MTC20
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Terminal Depopulated Quad Very-Thin Flat Pack No Leads (DQFN),
JEDEC MO-241, 2.5 x 4.5mm
20-Lead Shrink Small Outline Package (SSOP), JEDEC MO-150, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153,
4.4mm Wide
Note:
2. DQFN package available in Tape and Reel only.
Device also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering number.
All packages are lead free per JEDEC: J-STD-020B standard.
