FST10020 thru FST10040
Silicon Power
Schottky Diode
Features
• High Surge Capability
• Types from 20 V to 40V V
RRM
• Isolated to Plate
• Not ESD Sensitive
TO-249AB Package
V
RRM
= 20 V - 40 V
I
F(AV)
= 100 A
Maximum ratings, at T
j
= 25 °C, unless otherwise specified
Parameter
Repetitive peak reverse voltage
RMS reverse voltage
DC blocking voltage
Operating temperature
Storage temperature
Symbol
V
RRM
V
RMS
V
DC
T
j
T
stg
Conditions
FST10020
20
14
20
-55 to 150
-55 to 150
FST10030
30
21
30
-55 to 150
-55 to 150
FST10035
35
25
35
-55 to 150
-55 to 150
FST10040
40
28
40
-55 to 150
-55 to 150
Unit
V
V
V
°C
°C
Electrical characteristics, at Tj = 25 °C, unless otherwise specified
Parameter
Average forward current (per
pkg)
Peak forward surge current (per
leg)
Maximum instantaneous
forward voltage (per leg)
Maximum Instantaneous
reverse current at rated DC
blocking voltage (per leg)
Symbol
I
F(AV)
I
FSM
V
F
I
R
Conditions
T
C
= 125 °C
t
p
= 8.3 ms, half sine
I
FM
= 50 A, T
j
= 25 °C
T
j
= 25 °C
T
j
= 100 °C
T
j
= 150 °C
FST10020
100
1000
0.70
1
10
30
1.0
FST10030
100
1000
0.70
1
10
30
1.0
FST10035
100
1000
0.70
1
10
30
1.0
FST10040
100
1000
0.70
1
10
30
1.0
Unit
A
A
V
mA
Thermal characteristics
Thermal resistance, junction -
case (per leg)
R
ΘJC
°C/W
www.genesicsemi.com/silicon-products/schottky-rectifiers/
1
FST10020 thru FST10040
Package dimensions and terminal configuration
Product is marked with part number and terminal configuration.
N
A
P
C
E
G
J
L
M
1
2
3
B
K
F
H
R
Q
D
Inches
Min
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
Q
1.995
0.300
0.495
0.182
0.990
2.390
1.495
0.114
-----
0.256
0.490
0.330
0.175
0.035
0.445
0.890
Max
2.005
0.325
0.505
0.192
1.010
2.410
1.525
0.122
0.420
0.275
0.510
0.350
0.195
0.045
0.455
0.910
Min
50.67
7.62
12.57
4.62
25.15
60.71
37.90
2.90
-----
6.5
12.45
8.38
4.45
0.89
11.30
22.61
Millimeters
Max
50.93
8.26
12.83
4.88
26.65
61.21
38.70
3.10
10.67
7.0
12.95
8.90
4.95
1.14
11.56
23.11
www.genesicsemi.com/silicon-products/schottky-rectifiers/
3
