Product Brief
BGA734L16
Highly Integrated Tri-Band Low Noise Amplifier
for UMTS and HSxPA Systems
T h e B G A 7 3 4 L 1 6 is a highly integrated Low Noise Amplifier for 3G low,
mid, and high bands. Designed using a proprietary Silicon Germanium Carbon
process, the BGA734L16 delivers outstanding RF performance while optimizing cost,
battery life, and size.
High Level of Integration
In order to reduce front-end design complexity and minimize cost, the BGA734L16
monolithically integrates three amplifiers for cellular bands 800 Mhz, 1900 Mhz,
and 2100 Mhz on one die. Additional functions, including temperature stabilizing
block, 1kV hBM eSD protection, and output matching network are also integrated on
chip.
Battery Life Optimized
The BGA734L16 offers gain control capability for improving the dynamic range and
system performance in presence of high levels of interferers. Controlling the gain of
the LNA has also the advantage of extending battery life.
Small Form Factor
The BGA734L16 comes in a low profile, Tiny and Small Leadless Package code-
named TSLP-16. The package measures 2.3 x 2.3 x 0.39 mm
3
making this device
ideal for low profile multi-media phones and highly integrated front end modules.
Applications
■
■
■
handset
Data-Card
Module
Features
■
■
■
■
■
■
Internally matched output to 50
W
SiGe:C process
Shut down mode
Temperature stabilization
Two gain modes
Low external part count
Benefits
■
■
■
■
■
high level of integration
high linearity
Ultra-low noise figure
Small form factor
Low cost
TSLP-16 Package
2.3 x 2.3 x 0.39 mm
3
www.infineon.com/smallsignaldiscretes
Small Signal Discretes
Product Brief
Application Circuit
V
CC
= 2.8 V
C
7
0
GND
5 RFGNDH
10 nF 3
4
RFGNDH
V
CC
2
V
GS
V
GS
= 0/2.8 V
1
N.C.
RFIN
1900 MHz
C
1
10 pF
L
1
3.9 nH
C
2
1 nF
L
2
2.7 nH
6 RFINM
RFOUTM 16
RFOUT
1900 MHz
RFIN
2100 MHz
C
3
10 pF
C
4
1 nF
7 RFINH
RFOUTH 15
RFOUT
2100 MHz
8 RFGNDM
Biasing & Logic
Circuitry
9 RFGNDM
C
5
3 pF
C
6
1 nF
L
3
7.5 nH
RFINL
10
V
EN2
11
V
EN
= 0/2.8 V
RFOUTL 14
RFOUT
800 MHz
13
V
EN1
12
V
EN
= 0/2.8 V
N.C.
RFIN
800 MHz
High Gain Mode Performance
Supply Voltage: 2.8 V, Supply Current: 3.5 mA
Band [MHz]
800
1900
2100
Gain [dB]
14.5
15
15
Noise Figure [dB]
1.3
1.2
1.2
IP1dB [dB]
-15
-14
-14
IIP3 in Band [dB]
+1
-1
-1
Low Gain Mode Performance
Supply Voltage: 2.8 V, Supply Current: 0.5 mA
Band [MHz]
800
1900
2100
Gain [dB]
-8
-8
-8
Noise Figure [dB]
9
8.5
9
IP1dB [dB]
-7
-7
-7
IIP3 in Band [dB]
+1
+4
-1
