DATA SHEET
SKY13327-365LF: 0.25-2.15 GHz 4x2 Switch Matrix with
Tone/Voltage Detector
Applications
DBS switching systems
cable TV/modems
I3
I4
I2
I1
Features
Broadband frequency range: 0.25 to 2.15 GHz
Tone and voltage control switching
High isolation: 40 dB @ 900 MHz
Four RF inputs, two RF outputs
Low current consumption: 2.5 mA @ 5 V
Alternate truth Table logic using Skyworks SKY13369-365LF
Miniature QFN (20-pin, 4 x 4 mm) package (MSL1, 260
C
per
JEDEC J-STD-020)
OUT2
OUT1
V2
T2
Control Circuit
V1
T1
VDD
OMR
S1990
Figure 1. SKY13327-365LF Block Diagram
Description
The SKY13327-365LF is a four-input to two-output switch matrix
intended for Direct Broadcast Satellite (DBS) switching and cable
TV/modem applications. The SKY13327-365LF enables any of the
four inputs to either of the two outputs. Switch states can be
selected using tone and voltage signals together with vertical-
horizontal mirror control inputs. The load detection and Digital
Satellite Equipment Control (DiSEqC) rejection are integrated on
the switch.
The SKY13327-365LF rejects DiSEqC signals and responds only
to continuous-tone and voltage signals or vertical-horizontal
mirror control inputs. The switch on/off states are not changed by
DiSEqC signals, and only changed by continuous-tone and voltage
signals or vertical-horizontal mirror control inputs.
One of the two switch outputs can be deactivated when no-tone
and no-voltage are applied to one of the tone/voltage detectors.
Another Skyworks switch, the SKY13369-365LF, can be used to
reverse the I1, I2, I3, and I4 truth Table logic.
The SKY13327-365LF is manufactured in a compact, 4 x 4 mm,
20-pin Quad Flat No-Lead (QFN) package.
A functional block diagram is shown in Figure 1. The pin
configuration and package are shown in Figure 2. Signal pin
assignments and functional pin descriptions are provided in
Table 1.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
201291A • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • May 12, 2010
1
DATA SHEET • SKY13327-365LF 4X2 SWITCH MATRIX
OMR
GND
GND
17
I4
20
19
18
16
GND
I3
GND
V2
T2
I2
1
2
3
4
5
15
14
13
12
11
GND
I1
GND
V1
T1
6
7
8
9
10
OUT2
VDD
N/C
N/C
OUT1
S1992
Figure 2. SKY13327-365LF Pinout – 20-Pin QFN
(Top View)
Table 1. SKY13327-365LF Signal Descriptions
Pin #
1
2
3
4
5
6
7
8
9
10
GND
I3
GND
V2
T2
OUT2
N/C
VDD
N/C
OUT1
Name
Ground
RF input 3
Ground
Stereo left voltage detector input
Stereo left tone detector input
RF output 2
No connection. Pin may be grounded with no
change in performance.
Power supply voltage
No connection. Pin may be grounded with no
change in performance.
RF output 1
Description
Pin #
11
12
13
14
15
16
17
18
19
20
T1
V1
GND
I1
GND
I2
GND
OMR
GND
I4
Name
Description
Stereo right tone detector input
Stereo right voltage detector input
Ground
RF input 1
Ground
RF input 2
Ground
Vertical/horizontal mirror (see Table 4)
Ground
RF input 4
Electrical and Mechanical Specifications
The absolute maximum ratings of the SKY13327-365LF are
provided in Table 2. Electrical specifications are provided in
Table 3.
The state of the SKY13327-365LF is determined by the logic
provided in Table 4.
Typical performance characteristics of the SKY13327-365LF are
illustrated in Figures 3 through 10.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
2
May 12, 2010 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 201291A
DATA SHEET • SKY13327-365LF 4X2 SWITCH MATRIX
Table 2. SKY13327-365LF Absolute Maximum Ratings
Parameter
Supply voltage
RF input power
Storage temperature
Operating temperature
Note:
Symbol
V
DD
P
IN
T
STG
T
OP
Minimum
Typical
Maximum
6
+18
Units
V
dBm
C
C
–40
–40
+125
+85
Exposure to maximum rating conditions for extended periods may reduce device reliability. There is no damage to device with only one parameter set at the limit and all other
parameters set at or below their nominal value. Exceeding any of the limits listed here may result in permanent damage to the device.
CAUTION:
Although this device is designed to be as robust as possible, Electrostatic Discharge (ESD) can damage this device. This device
must be protected at all times from ESD. Static charges may easily produce potentials of several kilovolts on the human body
or equipment, which can discharge without detection. Industry-standard ESD precautions should be used at all times.
Table 4. SKY13327-365LF Electrical Specifications (Note 1)
(V
DD
= 5 V, T
OP
= +25
C,
P
IN
= 0 dBm, Characteristic Impedance [Z
O
] = 50
Ω,
Unless Otherwise Noted)
Parameter
RF Specifications
Insertion loss
IL
All states
0.25 to 0.95 GHz
0.95 to 2.15 GHz
Insertion loss flatness
All states
0.25 to 0.95 GHz
0.95 to 2.15 GHz
Isolation
Iso
Normalized to insertion
loss, all states
0.25 to 0.95 GHz
0.95 to 2.15 GHz
Input return loss
Output return loss
1 dB Input Compression Point
3
rd
Order Input Intercept Point
IP1dB
IIP3
0.25 to 0.95 GHz,
I1, I2, I3, I4, all states
0.25 to 2.15 GHz,
OUT1, OUT2, all states
@ 2.15 Ghz
@ 2.15 Ghz,
1 MHz spacing,
P
IN
= –12 dBm/tone
35
25
12
7
+13
37
31
15
12
+15
+25
dB
dB
dB
dB
dBm
dBm
1.0
1.0
1.5
1.5
dB
dB
8
9
9
10
dB
dB
Symbol
Test Condition
Min
Typical
Max
Units
Tone/Voltage Detector Specifications
Polarization select threshold voltage
Switching time
Tone frequency
Tone threshold voltage
Power Supply
Supply voltage
Supply current
I
CC
3.3
5.0
2.5
5.5
V
mA
With external 10 nF series
capacitor
14.9
1.3
14
15.0
1.5
22
90
15.2
6.2
442
V
ms
kHz
mVp-p
Note 1:
Performance is guaranteed only under the conditions listed in this Table.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
201291A • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • May 12, 2010
3
DATA SHEET • SKY13327-365LF 4X2 SWITCH MATRIX
Table 4. SKY13327-365LF Truth Table
State
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Note:
V1
(Pin 12)
V
LOW
V
LOW
V
LOW
V
LOW
V
LOW
V
LOW
V
LOW
V
LOW
V
HIGH
V
HIGH
V
HIGH
V
HIGH
V
HIGH
V
HIGH
V
HIGH
V
HIGH
No Voltage
No Voltage
No Voltage
No Voltage
V
LOW
V
LOW
V
HIGH
V
HIGH
T1
(Pin 11)
No Tone
No Tone
No Tone
No Tone
22 kHz Tone
22 kHz Tone
22 kHz Tone
22 kHz Tone
No Tone
No Tone
No Tone
No Tone
22 kHz Tone
22 kHz Tone
22 kHz Tone
22 kHz Tone
No Tone
No Tone
No Tone
No Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
V2
(Pin 4)
V
LOW
V
LOW
V
HIGH
V
HIGH
V
LOW
V
LOW
V
HIGH
V
HIGH
V
LOW
V
LOW
V
HIGH
V
HIGH
V
LOW
V
LOW
V
HIGH
V
HIGH
V
LOW
V
LOW
V
HIGH
V
HIGH
No Voltage
No Voltage
No Voltage
No Voltage
T2
(Pin 5)
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
22 kHz Tone
No Tone
No Tone
No Tone
No Tone
Signal Path
Pin 18 (OMR) Open
I1 to OUT2, I1 to OUT1
I2 to OUT2, I1 to OUT1
I3 to OUT2, I1 to OUT1
I4 to OUT2, I1 to OUT1
I1 to OUT2, I2 to OUT1
I2 to OUT2, I2 to OUT1
I3 to OUT2, I2 to OUT1
I4 to OUT2, I2 to OUT1
I1 to OUT2, I3 to OUT1
I2 to OUT2, I3 to OUT1
I3 to OUT2, I3 to OUT1
I4 to OUT2, I3 to OUT1
I1 to OUT2, I4 to OUT1
I2 to OUT2, I4 to OUT1
I3 to OUT2, I4 to OUT1
I4 to OUT2, I4 to OUT1
I1 to OUT2
I2 to OUT2
I3 to OUT2
I4 to OUT2
I1 to OUT1
I2 to OUT1
I3 to OUT1
I4 to OUT1
Pin 18 (OMR) Connected to
Ground
I3 to OUT2, I3 to OUT1
I4 to OUT2, I3 to OUT1
I1 to OUT2, I3 to OUT1
I2 to OUT2, I3 to OUT1
I3 to OUT2, I4 to OUT1
I4 to OUT2, I4 to OUT1
I1 to OUT2, I4 to OUT1
I2 to OUT2, I4 to OUT1
I3 to OUT2, I1 to OUT1
I4 to OUT2, I1 to OUT1
I1 to OUT2, I1 to OUT1
I2 to OUT2, I1 to OUT1
I3 to OUT2, I2 to OUT1
I4 to OUT2, I2 to OUT1
I1 to OUT2, I2 to OUT1
I2 to OUT2, I2 to OUT1
I3 to OUT2
I4 to OUT2
I1 to OUT2
I2 to OUT2
I3 to OUT1
I4 to OUT1
I1 to OUT1
I2 to OUT1
V
LOW
= 10 V ~ 14 V
V
HIGH
= 16 V ~ 21 V
No Tone = No 22 kHz tone present
22 kHz Tone = 22 kHz tone present with amplitude greater than 100 mVp-p
No Voltage = < 5 V
Any state other than described in this Table places the switch into an undefined state. An undefined state will not damage the device.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
4
May 12, 2010 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • 201291A
DATA SHEET • SKY13327-365LF 4X2 SWITCH MATRIX
Typical Performance Characteristics
(V
DD
= 5 V, T
OP
= +25
C,
P
IN
= 0 dBm, Characteristic Impedance [Z
O
] = 50 Ω, Unless Otherwise Noted)
0
–10
Insertion Loss and Isolation (dB)
–20
–30
–40
–50
–60
–70
–80
–90
0.25 0.35 0.45 0.55 0.65 0.75 0.85 0.95 1.05 1.15 1.25 1.35 1.45 1.55 1.65 1.75 1.85 1.95 2.05 2.15
1
11
21
2
12
22
3
13
23
4
14
24
5
15
6
16
7
17
8
18
9
19
10
20
Frequency (GHz)
Figure 3. I1 to OUT1 for States 1 to 24
0
–10
Insertion Loss and Isolation (dB)
–20
–30
–40
–50
–60
–70
–80
1
11
21
2
12
22
3
13
23
4
14
24
5
15
6
16
7
17
8
18
9
19
10
20
–90
0.25 0.35 0.45 0.55 0.65 0.75 0.85 0.95 1.05 1.15 1.25 1.35 1.45 1.55 1.65 1.75 1.85 1.95 2.05 2.15
Frequency (GHz)
Figure 4. I2 to OUT1 for States 1 to 24
0
–10
Insertion Loss and Isolation (dB)
–20
–30
–40
–50
–60
–70
–80
1
11
21
2
12
22
3
13
23
4
14
24
5
15
6
16
7
17
8
18
9
19
10
20
–90
0.25 0.35 0.45 0.55 0.65 0.75 0.85 0.95 1.05 1.15 1.25 1.35 1.45 1.55 1.65 1.75 1.85 1.95 2.05 2.15
Frequency (GHz)
Figure 5. I3 to OUT1 for States 1 to 24
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
201291A • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • May 12, 2010
5
