GSD2004W
www.vishay.com
Vishay Semiconductors
Small Signal Switching Diode, High Voltage
FEATURES
• Silicon epitaxial planar diode
• Fast switching diode, especially suited for
applications requiring high voltage capability
• AEC-Q101 qualified available
• Base P/N-E3 - RoHS-compliant, commercial
grade
• Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
MECHANICAL DATA
Case:
SOD-123
Weight:
approx. 10.3 mg
Packaging codes / options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
GSD2004W
ORDERING CODE
GSD2004W-E3-08 or GSD2004W-E3-18
GSD2004W-HE3-08 or GSD2004W-HE3-18
CIRCUIT CONFIGURATION
Single
TYPE MARKING
B6
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Continuous reverse voltage
Repetitive peak reverse voltage
Forward current (continuous)
Repetitive peak forward current
Non-repetitive peak forward current
Power dissipation
(1)
t
p
= 1 μs
t
p
= 1 s
TEST CONDITION
SYMBOL
V
R
V
RRM
I
F
I
FRM
I
FSM
I
FSM
P
tot
VALUE
240
300
225
625
4
1
350
UNIT
V
V
mA
mA
A
A
mW
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Typical thermal resistance junction to ambient air
(1)
Junction temperature
Storage temperature range
Operating temperature range
Note
(1)
Valid provided that electrodes are kept at ambient temperature
TEST CONDITION
SYMBOL
R
thJA
T
j
T
stg
T
op
VALUE
357
150
-65 to +150
-55 to +150
UNIT
K/W
°C
°C
°C
Rev. 1.8, 23-Feb-18
Document Number: 85729
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GSD2004W
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
R
= 100 μA
V
R
= 240 V
V
R
= 240 V, T
j
= 150 °C
I
F
= 100 mA
I
F
= 20 mA
V
F
= V
R
= 0, f = 1 MHz
SYMBOL
V
(BR)
I
R
I
R
V
F
V
F
C
D
t
rr
0.83
MIN.
300
100
100
1
0.87
5
50
TYP.
MAX.
UNIT
V
nA
μA
V
V
pF
ns
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse breakdown voltage
Leakage current
Forward voltage
Diode capacitance
Reverse recovery time
I
F
= I
R
= 30 mA, i
R
= 3 mA,
R
L
= 100
PACKAGE DIMENSIONS
in millimeters (inches):
SOD-123
0.1 (0.004) max.
1.35 (0.053)
8°
0.45 (0.018)
0.25 (0.010)
0.5 (0.020) ref.
Cathode bar
2.85 (0.112)
2.55 (0.100)
0.15 (0.006)
0.10 (0.004)
1 (0.039)
0.2 (0.008)
0° to
Mounting Pad Layout
0.85 (0.033)
0.85 (0.033)
0.65 (0.026)
0.45 (0.018)
3.85 (0.152)
3.55 (0.140)
1.40 (0.055)
1.7 (0.067)
2.5 (0.098)
Rev. 4 - Date: 24. Sep. 2009
Document no.: S8-V-3910.01-001 (4)
17432
Rev. 1.8, 23-Feb-18
Document Number: 85729
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0.85 (0.033)
