PCB terminal block - FFKDSA1/V-2,54-21 BD:3-23 - 1724187
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB terminal block, Nominal current: 6 A, Nom. voltage: 160 V, Pitch: 2.54 mm, Number of positions: 20,
Connection method: Push-in spring connection, Mounting: Wave soldering, Conductor/PCB connection
direction: 90 °, Color: green
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4046356124119
85369010
Made to Order (non-returnable)
10 STK
Technical data
Dimensions
Length
Pitch
Dimension a
Constructional height
Length of the solder pin
Pin dimensions
Hole diameter
12.6 mm
2.54 mm
50.8 mm
14 mm
3.4 mm
0,5 x 0,8 mm
1.1 mm
General
Range of articles
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Solder pin surface
FFKDS(A)/V
2.5 kV
2.5 kV
2.5 kV
63 V
160 V
320 V
EN-VDE
6A
0.5 mm²
Sn
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1724187
PCB terminal block - FFKDSA1/V-2,54-21 BD:3-23 - 1724187
Technical data
General
Stripping length
Number of positions
11 mm
20
Connection data
Conductor cross section AWG min.
Conductor cross section AWG max.
26
20
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Approvals
Approvals
Approvals
CSA / UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approval details
CSA
http://www.csagroup.org/services/testing-and-certification/certified-product-listing/ 13631
B
20
6A
150 V
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-20
6A
150 V
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1724187
PCB terminal block - FFKDSA1/V-2,54-21 BD:3-23 - 1724187
Approvals
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-20
6A
150 V
EAC B.01742
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
11/14/2016 Page 3 / 3
