This document was generated on 03/02/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0349006141
Active
MXP120 Sealed Connector System
MXP120 Sealed Receptacle, 6 Circuit, Black Housing with Long Shroud (T3-V2-S3 with
Backshell, T3-V2-S2 without Backshell), Key B, Light Gray Insert
Documents:
3D Model
Drawing (PDF)
Product Specification PS-34900-0001-001 (PDF)
Application Specification AS-34900-0001-001 (PDF)
General
Product Family
Series
Application
Application Tooling Part Link
Comments
Overview
Polarization
Product Literature Order No
Product Name
UPC
Physical
Circuits (maximum)
Color - Resin
Gender
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Application Specification AS-34900-0001-CH-001
(PDF)
Packaging Specification PK-31301-898-001 (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
Compliant
Crimp Housings
34900
Body Electronics, Sealed, Wire-to-Wire
63824-6300
See sales drawing for terminal information.
MXP120 Sealed Connector System
B
987650-7994
MXP120 Sealed
889056198042
6
Black
Receptacle
No
Yes
Yes
SPS/Nylon
6.500/g
1
Bag
No
4.00mm
4.00mm
Yes
-40°C to +125°C
13.0A
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
Search Parts in this Series
34900 Series
Mates With
MXP120 Male Blade Connector 34899
Use With
MXP120 Backshell 160091-6020 ,
160091-6120 , 160091-6220 <br>MXP120
Cavity Plug 34996-1501 <br>MXP120
Cavity Plug Seal 34996-1902 <br>1.2 LL
SWS from Tyco and Kostal
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
AS-34900-0001-001, AS-34900-0001-CH-001
PK-31301-898-001
PS-34900-0001-001
SD-34900-2001-001, SD-34900-6001
