1705852 Overview

Fixed Terminal Blocks SPTA 1,5/ 2- 5,08 BD:1,1 SO

1705852 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK
Base Number Matches	1

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1705852

SPTA 1,5/ 2-5,08 BD:1,1 SO - 1705852

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 9 A, Nom. voltage: 320 V, Pitch: 5.08 mm, Number of positions: 2,

Connection method: Push-in spring connection, Mounting: Wave soldering, Conductor/PCB connection

direction: 45 °, Color: green

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356803762

85369010

Made to Order (non-returnable)

100 STK

Technical data

Dimensions

Pitch

Dimension a

Length of the solder pin

Pin dimensions

Pin spacing

Hole diameter

5.08 mm

3.4 mm

0,6 x 1,0 mm

7 mm

1.1 mm

General

Range of articles

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

N

Nominal cross section

Solder pin surface

Stripping length

SPTA 1,5/

4 kV

250 V

320 V

630 V

EN-VDE

9A

1.5 mm²

Sn

10 mm

11/14/2016 Page 1 / 3
