MALE PCB
PINS
PRINTED CIRCUIT PINS
3110/3111
Swage mount in .043 hole
.025 DIA.
.040 DIA.
.070 DIA.
311X-X-00-XX-00-00-08-0
3150
Basic
Part
Number
V
Board
Thick-
ness
3150-X-00-XX-00-00-08-0
Length
A
Length
V
Swage mount in .043 mounting hole
.025 DIA.
.040 DIA.
.070 DIA.
.020
.580
.030 DIA.
.045
.040
.020
A
.030 DIA.
3110-1
3110-2
3110-3
3111-1
3111-2
3111-3
.031
.062
.094
.031
.062
.094
.150
.150
.150
.300
.300
.300
.051
.082
.113
.051
.082
.113
V
Basic Part
Number
Board
Thickness
Length
V
3150-1
3150-2
.031
.062
.051
.082
3136/3137
313X-X-00-XX-00-00-08-0
Solder mount in .043 mounting hole
3137-1 is available on 16mm wide
carrier tape: 580 parts per 13” reel.
See page 224.1 for Tape & Reel details
.040 DIA.
C DIA.
.040
V
Basic
Part
Number
Board
Thick-
ness
Length
V
Flange
Dia.
C
3148
.040 DIA.
.058 DIA.
3148-3-00-XX-00-00-08-0
Swage mount in .062 hole
For a .094 thick board
8815
.075 DIA.
8815-0-00-XX-00-00-03-0
Hex press-fit in .066 plated through-hole
.030
.047
.060 DIA.
.015
.190
3136-1
3136-2
3136-3
3137-1
3137-2
3137-3
3137-4
.062
.094
.125
.062
.094
.125
.156
.082
.110
.145
.082
.110
.145
.185
.078
.100 .125
.030
.093 DIA.
.030 DIA.
.030 DIA.
.180
.062
.030 DIA.
.240
.070 DIA.
.120
6821
6821-0-00-XX-00-00-08-0
Turret terminal pin
.070 DIA.
.015
.040 DIA.
.020
.070 DIA.
.030 DIA.
.125
.320
3132
.040 DIA.
.093 DIA.
.060 DIA.
.093 DIA.
3132-0-00-XX-00-00-08-0
5601
.030 DIA.
Wire crimp termination, Annnealed
Accepts wire sizes 22 AWG Max. / 24 AWG Min.
5601-0-01-XX-00-00-03-0
5602
.191
.030 DIA.
.072 DIA.
Compliant press-fit in .040 ± .003 plated
through-hole. For .060”
g.100”
thick board
5602-0-01-XX-00-00-03-0
Compliant press-fit in .040 ± .003 plated
through-hole. For .090”
g.130”
thick board
.012
.191
.030
.100
.030
.155
.012
.072 DIA.
.060 DIA.
.038 DIA.
.045 DIA.
.026 DIA.
HOLE
.035 DIA.
.045
.042
.124
.010
(TYP)
.091
.060 DIA.
.038 DIA.
.045 DIA.
.026 DIA.
HOLE
.035 DIA.
.045
.050
.091
.030 DIA.
.240
.163
.010
(TYP)
.018
SLOT
.018
SLOT
PAGE 220 | MALE PCB PINS
SPECIFICATIONS:
Pin Material:
Brass Alloy 360, 1/2 Hard
( Except swage pins which are annealed )
Dimensions: Inches
Tolerances On:
Lengths: ± .005
Diameters: ± .002
Angles:
±2°
ORDER CODE: XXXX - X - 0X -
XX
- 00 - 00 - XX - 0
BASIC PART #
SPECIFY PIN FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
15
10
μ”
GOLD OVER NICKEL (RoHS)
21
20
μ”
GOLD OVER NICKEL (RoHS)
34
50
μ”
GOLD OVER NICKEL (RoHS)
2011/65/EU
RoHS - 2
