Type WMC
Polyester Film/Foil Capacitors
Axial Lead, Miniature Size for Automatic Insertion
Type WMC axial-leaded polyester film/foil capacitors
are ideal for automatic insertion in printed circuit
boards. It is an ultraminiature version of Type WMF
and the sections of these non-inductive capacitors
are constructed with extended foil, polyster film, with
tinned copper-clad steel leads.
Highlights
•
•
•
•
•
Miniature Size
Available on tape and reel
Film/foil construction, non-inductive design
High dV/dt ratings
Good for high pulse applications
Specifications
Specifica-
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Temperature Range:
Complies with the EU Directive 2002/95/
EC requirement restricting the use of
Lead (Pb), Mercury (Hg), Cadmium
(Cd), Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB) and
PolyBrominated Diphenyl Ethers (PBDE).
.001 µF to .47 µF
80 to 400 Vdc
±10% standard, ±5% optional
–55 to +125 ºC
(Full-rated voltage at 85 °C–Derate linearly to 50%-rated voltage at 125 °C)
Dielectric Strength:
Dissipation Factor:
Insulation Resistance:
Life Test:
250% of rated voltage for 1 minute
.75% Max. (25 ºC, 1 kHz)
30,000 MΩ
x µF, 100,000 MΩ Min.
250 hours at 85 ºC at 125% rated voltage
Outline Drawing
d
1.5” Min.
(38 mm)
Tinned Copper-Clad Steel Leads
1.5” Min.
(38 mm)
Pulse Ratings
Pulse Capability
Body Length
Rated
Voltage
80
200
400
≤.437
.531-.593
.656-.718
0.906
1.218
L Max.
D
Max.
dV/dt — volts per microsecond, maximum
5000
10800
30700
2100
5000
14500
1500
3000
9600
900
1700
3600
690
1260
2600
Lead Diameters:
No. 24 AWG to .282” (6.35mm) diameter
No. 22 AWG .283” (6.38mm) diameter and up
NOTE: Other capacitance values, sizes and performance specifications are
available. Contact us.
Ratings
Cap
(µF)
Catalog
Part Number
D
80 Vdc
0.0010
WMC08D1K-F
0.0012
WMC08D12K-F
0.0015
WMC08D15K-F
0.0018
WMC08D18K-F
0.0022
WMC08D22K-F
0.0027
WMC08D27K-F
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
0.0033 WMC08D33K-F
0.0039 WMC08D39K-F
0.0047
WMC08D47K-F
0.0056 WMC08D56K-F
0.0068 WMC08D68K-F
0.0082
WMC08D82K-F
L
d
Cap
(µF)
Catalog
Part Number
D
80 Vdc
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.185 (4.7)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.406 (10.3)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
.020 (.5)
L
d
Inches (mm) Inches (mm) Inches (mm)
Inches (mm) Inches (mm) Inches (mm)
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type WMC
Polyester Film/Foil Capacitors
Notice and Disclaimer:
All product drawings, descriptions, specifications, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confirming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifically and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specific customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specified by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
