Crystal unit
Product Number (please contact us)
MHz RANGE CRYSTAL UNIT
FA-238V : Q22FA23V0xxxx17
FA-238
: Q22FA2380xxxx17
TSX-3225 : X1E000021xxxx16
FA - 238V
/
FA - 238
TSX - 3225
•Frequency
range
:
•
External dimensions
:
:
•Overtone
order
:
•Applications
:
:
12 MHz to 60 MHz(FA-238,FA-238V)
3.2 × 2.5 × 0.6 mm ···TSX-3225
3.2 × 2.5 × 0.7 mm ···FA-238V / FA-238
Fundamental
Mobile phone, Bluetooth, W-LAN
ISM band radio, Clock for MPU
Actual size
FA-238V
/
FA-238
TSX-3225
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature
Operating temperature
Level of drive
Frequency tolerance
Frequency versus
temperature characteristics
Load capacitance
Motional resistance (ESR)
Frequency aging
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
CL
R
1
f_age
For Clock
For RF Reference
FA-238V
FA-238
TSX-3225
12.000 MHz to
16.000 MHz to
16.000 MHz to
15.999 MHz
60.000 MHz
48.000 MHz
-40
°C
to +125
°C
-40
°C
to +85
°C
(+105
°C)
200
µW
Max.
±50 ×
10
-6
(standard),
±10 ×
10
-6
(±15
×
10
-6
to
±50 ×
10
-6
is available)
±30 ×
10
-6
/
-20
°C
to +70
°C
7 pF to
∞
As per table below
±5 ×
10
-6
/ year Max.
As per table below
±1 ×
10
-6
/ year Max.*2
±10 ×
10
-6
/
-20
°C
to +75
°C
Conditions / Remarks
Fundamental
*1
Please contact us about available frequencies.
Storage as single product.
Please contact us about +85
°C
< T_use
Recommended: 1 to 100
µW
+25
°C
Please contact us for requirements not
listed in this specifications.
*1
Please contact us for requirements not listed in
this specifications.
*1
Please specify.
-40
°C
to +85
°C,
DL = 100
µW
+25
°C,
First year
*1
FA-238: For over 40 MHz, only the standard specification applies.
*2
40 MHz
≤
f_nom :
±2 ×
10
-6
/ year Max.
(TSX-3225)
Frequency
16.0 MHz
≤
f_nom < 21.0 MHz
21.0 MHz
≤
f_nom
≤
48.0 MHz
Motional resistance
60 Max.
40 Max.
Motional resistance (ESR)
(FA-238V / FA-238)
Frequency
12.0 MHz
≤
f_nom
≤
13.0 MHz
13.0 MHz < f_nom < 20.0 MHz
20.0 MHz
≤
f_nom < 25.0 MHz
25.0 MHz
≤
f_nom < 30.0 MHz
30.0 MHz
≤
f_nom
≤
60.0 MHz
Product name
(Standard form)
FA-238V
Motional resistance
100 Max.
80 Max.
60 Max.
50 Max.
40 Max.
12.000000MHz
12.0 +15.0-15.0
-6
Model
Frequency
Load capacitance(pF)
Frequency tolerance(
×
10
,
+25
°C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
External dimensions
FA-238V
#4
#3
(Unit:mm)
FA-238
#4
#3
2.5±0.1
TSX-3225
#4
#3
2.5±0.15
1200M
V66RA
#1
3.2±0.1
2000M
E66RA
#1
3.2±0.1
2.5±0.1
Internal connection
(TOP VIEW)
#4
#3
#1
#2
Marking
#1
#2
0.7 Max.
#2
0.7 Max.
3.2±0.15
#2
0.6 Max.
#2 and #4
are connected to the cover.
(Please connect to ground)
1.2
#1
#2
#1
1.2
#2
#1
1.0
#2
0.7
C 0.3 Min.
0.8
#4
0.9
#3
#4
0.8
0.9
#3
#4
1.0
#3
Footprint (Recommended)
FA-238V / FA-238
2.2
TSX-3225
2.2
0.8 0.7
0.7
(Unit:mm)
1.6
1.2
1.4
1.6
1.15
1.4
PROMOTION OF ENVIRONMENTAL MANAGEMENT SYSTEM
CONFORMING TO INTERNATIONAL STANDARDS
At Seiko Epson, all environmental initiatives operate under the
Plan-Do-Check-Action (PDCA) cycle designed to achieve continuous
improvements. The environmental management system (EMS)
operates under the ISO 14001 environmental management standard.
All of our major manufacturing and non-manufacturing sites, in
Japan and overseas, completed the acquisition of ISO 14001
certification.
ISO 14000 is an international standard for environmental
management that was established by the International
Standards Organization in 1996 against the background of
growing concern regarding global warming, destruction of
the ozone layer, and global deforestation.
WORKING FOR HIGH QUALITY
In order provide high quality and reliable products and services
than meet customer needs,
Seiko Epson made early efforts towards obtaining ISO9000 series
certification and has acquired ISO9001 for all business
establishments in Japan and abroad. We have also acquired ISO/TS
16949 certification that is requested strongly by major automotive
manufacturers as standard.
►Explanation
of the mark that are using it for the catalog
►Pb
free.
►Complies
with EU RoHS directive.
*About the products without the Pb-free mark.
Contains Pb in products exempted by EU RoHS directive.
(Contains Pb in sealing glass, high melting temperature type solder or other.)
►Designed
for automotive applications such as Car Multimedia, Body Electronics, Remote Keyless Entry etc.
ISO/TS16949 is the international standard that added the
sector-specific supplemental requirements for automotive
industry based on ISO9001.
►Designed
for automotive applications related to driving safety (Engine Control Unit, Air Bag, ESC etc ).
