LEADED FERRITE BEAD INDUCTORS(FB SERIES A TYPE / R TYPE)
LEADED FERRITE BEAD INDUCTORS (FB SERIES A TYPE / R TYPE)
■PARTS
NUMBER
*Operating Temp. : -25½+105℃（Including self-generated heat）
WAVE
WAVE
F
①
B
A
②
0
③
4
H
④
A
4
5 0
⑤
B
⑥
B
－ 0 0
⑦
△＝Blank space
①Series name
Code
FB
②Shape
Code
A
R
Series name
Ferrite bead
Shape
Axial lead
Radial lead
③Dimensions of core（D）
Code
Dimensions of core（D）［mm½
03
φ2.5
04
φ3.5
05
5.0
06
6.0
07
7.5
④Material
Code
HA
VA
⑤Nominal impedance
Code
（example）
850
121
⑥Lead configuration
Code
Lead configurations［mm½
AB
Straight lead (26mm lead space) / ammo
BB
Straight lead (52mm lead space) / ammo
KD
Formed lead (10mm pitch) / bulk
KE
Formed lead (12.5mm pitch) / bulk
KF
Formed lead / bulk (15.0mm pitch) / bulk
Lead (2.5mm pitch)/bulk (FBR)
NA
Straight lead / bulk (FBA)
NB
Formed lead (crimped) / bulk
SA
Straight lead (FBR05 type) / ammo
SB
Straight lead (FBR07 type) / ammo
TB
Straight lead (FBR07 type) / ammo
UB
Radial lead formed / ammo
US
Formed lead (crimped) / bulk
VB
Dual side lead formed (crimped) / ammo
VS
Formed lead / bulk
⑦Internal code
Code
－00
NOISE SUPPRESSION COMPONENTS FERRITE BEAD INDUCTORS
Material
Refer to impedance curves
for material differences
Internal code
Standard
Nominal impedance［Ω min.½
85
120
Excluding 03type
／
■STANDARD
EXTERNAL DIMENSIONS / STANDARD QUANTITY
i_leaded_FBA_FBR_e-E06R01
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
1
8
141
Unit：mm（inch）
□Please specify the lead configuration code.
Note: Lead diameter (φd) shall fall within a range of 0.65mm±0.05mm, FBR07 types however, will have a lead diameter (φd) range of 0.6mm±0.05mm.
NOISE SUPPRESSION COMPONENTS FERRITE BEAD INDUCTORS
／
142
■PARTS
NUMBER
●FBA
Parts number
FBA03△450[]-00
FBA04△450[]-00
FBA04△600[]-00
FBA04△900[]-00
EHS
RoHS
RoHS
RoHS
RoHS
Nominal
impedance
［Ω
½（min.）
35
45
60
90
Impedance measuring frequency
［MH½½
Material
HA
VA
50
100
50
100
50
100
50
100
Rated current
［A½（max.）
Material
HA
7.0
7.0
7.0
7.0
VA
7.0
7.0
7.0
7.0
DC Resistance
［Ω
½（max.）
0.01
0.01
0.01
0.01
Rated current
［MΩ
½（min.）
1.0
1.0
1.0
1.0
●FBR
Parts number
FBR05VA121[]-00
FBR06△850NA-00
FBR06△121NA-00
FBR07△850[]-00
FBR07△121[]-00
EHS
RoHS
RoHS
RoHS
RoHS
RoHS
Nominal
impedance
［Ω
½（min.）
120
85
120
85
120
Impedance measuring frequency
［MH½½
Material
HA
VA
-
100
50
100
50
100
50
100
50
100
Rated current
［A½（max.）
Material
HA
-
7.0
7.0
7.0
7.0
VA
7.0
7.0
7.0
7.0
7.0
DC Resistance
［Ω
½（max.）
0.01
0.01
0.01
0.01
0.01
Rated current
［MΩ
½（min.）
1.0
1.0
1.0
1.0
1.0
※△Please specify material codes (HA,VA) and [] lead configuration code.
i_leaded_FBA_FBR_e-E06R01
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
1
8
