MLCC Tin/Lead Termination “B”
General Specifications
AVX Corporation will support those customers for
commercial and military Multilayer Ceramic Capacitors with
a termination consisting of 5% minimum lead. This
termination is indicated by the use of a “B” in the 12th
position of the AVX Catalog Part Number. This fulfills AVX’s
commitment to providing a full range of products to our
customers. AVX has provided in the following pages a full
range of values that we are currently offering in this special
“B” termination. Please contact the factory if you require
additional information on our MLCC Tin/Lead Termination
“B” products.
Not RoHS Compliant
PART NUMBER (see page 2 for complete part number explanation)
LD05
Size
LD02 - 0402
LD03 - 0603
LD04 - 0504*
LD05 - 0805
LD06 - 1206
LD10 - 1210
LD12 - 1812
LD13 - 1825
LD14 - 2225
LD20 - 2220
5
Voltage
6.3V = 6
10V = Z
16V = Y
25V = 3
35V = D
50V = 5
100V = 1
200V = 2
500V = 7
A
Dielectric
C0G (NP0) = A
X7R = C
X5R = D
X8R = F
101
Capacitance
Code (In pF)
2 Sig. Digits +
Number of
Zeros
J
A
B
2
A
Special
Code
A = Std.
Product
B
C
D
F
G
J
K
M
Capacitance
Failure
Terminations
Packaging
Tolerance
Rate
2 = 7" Reel
B = 5% min lead
= ±.10 pF (<10pF) A = Not X = FLEXITERM
®
4 = 13" Reel
= ±.25 pF (<10pF) Applicable
with 5% min
= ±.50 pF (<10pF)
Contact Factory
lead**
= ±1% (≥ 10 pF)
For
= ±2% (≥ 10 pF)
Multiples
**X7R only
= ±5%
= ±10%
= ±20%
*LD04 has the same CV ranges as LD03.
NOTE: Contact factory for availability of Tolerance Options for Specific Part Numbers.
Contact factory for non-specified capacitance values.
See FLEXITERM
®
section
for CV options
NP0
X7R
X7S
X5R
Y5V
Refer to page 4 for Electrical Graphs
Refer to page 19 for Electrical Graphs
Refer to page 23 for Electrical Graphs
Refer to page 26 for Electrical Graphs
Refer to page 30 for Electrical Graphs
40
