Temperature Compensated Crystal Oscillators (TCXO, VCTCXO)
Surface Mount Type TCXO (LSI Type) KT5032 Series for Smallcell/ Stratum3
5.0×3.2mm
Features
• High stability and high reliability
• 2.3 to 3.63V drive available
• Clipped sine wave or CMOS level
output
• Low phase noise
How to Order
KT5032F 20000
□
A
□
33 T xx
①
②
③ ④ ⑤ ⑥ ⑦ ⑧
①
Series
②
Output Frequency
Frequency Tolerance
④
Lower Operating Temp.
③
⑤
Upper Operating Temp.
KAW
KAY
AAY
33
③
±
0.28
×
10
−
6
±
0.28
×
10
−
6
±
0.10
×
10
−
6
3.3V
④
−
40
°
C
−
40
°
C
−
40
°
C
⑤
+
85
°
C
+
105
°
C
+
105
°
C
Applications
• 5G, Smallcell, Stratum3
• SONET/ SDH/ Ethernet
⑥
Supply Voltage
⑦
Voltage Control Function
T
TCXO
Spec. Code
*
VCTCXO
*
Please contact us for Spec. Code.
RoHS Compliant
⑧
Individual Specification
Packaging (Tape & Reel 1000 pcs./ reel)
Specifications
Item
Output Frequency Range
Frequency Tolerance
Supply Voltage
Current Consumption
Frequency Aging
Voltage Control Range
Output Level
Low Level Output Voltage
High Level Output Voltage
Rise / Fall Time
(10%Vcc to 90%Vcc)
Symmetry
Symbol
fo
f
_tol
V
CC
I
CC
f
_age
f
_cont
Vpp
V
OL
V
OH
tr/ tf
SYM
Conditions
Standard Frequency: 10, 19.2, 20, 24.576, 26, 30.72, 38.88, 40
vs Temperature (
−
10 to
+
105
°
C) [
±
(fmax-fmin)/ 2fo]
vs Temperature (
−
40 to
+
85
°
C/
+
105
°
C) [
±
(fmax-fmin)/ 2fo]
vs Voltage
CMOS Output
20years aging @40
°
C Including temp characteristics, initial
tolerance, rated power supply voltage change and load change.
Positive
*
100k ohm min
Clipped Sine
*
, Load: 10k ohm // 10pF
CMOS, Load: 15pF I
OL
=
4mA
CMOS, Load: 15pF I
OH
=−
4mA
CMOS, Load: 15pF
50% Vcc
@10Hz offset
@100Hz offset
@1kHz offset
@10kHz offset
@100kHz offset
Min.
10
−
0.1
−
0.28
−
0.1
+
2.3
—
−
4.6
±
5
0.8
—
90% V
CC
—
45
—
—
—
—
—
Max.
40
+
0.1
+
0.28
+
0.1
+
3.63
6
+
4.6
±
20
—
10% V
CC
—
8
55
−
90
−
120
−
140
−
150
−
150
Units
MHz
×
10
−
6
V
mA
×
10
−
6
×
10
−
6
Vp-p
V
V
ns
%
Phase Noise
—
@20MHz
dBc/ Hz
*
: A DC-cut capacitor is not embedded in this crystal oscillator. In case of clipped sine output, connect a DC-cut capacitor (
≥
1nF) to the line-out terminal of the oscillator.
*
Please contact us for other specifications.
Dimensions
5.0 0.2
#9
3.2 0.2
#8
#7
#6
(Unit: mm)
Recommended Land Pattern
Top view
Type A (without Filter)
if output is Clipped Sine.
4.5
0.01 F
(Unit: mm)
#10
Marking Area
#5
0.01 F
To GND
#9
#6
#1
#2
#3
#4
1.7 max
1.0
#1
1.0
#4
4 0.6
#1
#2
#3
4 0.65
0.1
#4
Pin Configuration
#1pin Voltage Control (VCTCXO), GND (TCXO)
#2pin Do not connect
#3pin Do not connect
#4pin GND
#5pin GND
#6pin Output
#7pin Vcfilter/ N/ C
#8pin Do not connect
#9pin Vcc
#10pin GND
Type
Ｂ
(with Filter)
Option
VC_Filter Cap.
0.01 F
To GND
#9
#10
1.0
#1
#2
#3
0.7
4.5
1.2
#8
#7
#6
#5
#4
To GND
if output is Clipped Sine.
0.01 F
0.65
2 0.6
#10
#5
4 0.8
2.3
4 0.43
0.63
1.2
1.0
0.1
#9
#8
#7
#6
2.67
Note: A capacitor of value
0.01 F between V
CC
and
GND is recommended.
2.3
As of March 2018
