5566-2013 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 5566-2013

5566-2013: DescriptionBoard Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal; CategoryThe connector; File Size68KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric Compare View All

5566-2013 Overview

Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal

5566-2013 Parametric

Parameter Name	Attribute value
Maker	Molex
Reach Compliance Code	unknown
Is Samacsys	N
Other features	COMPATIBLE CONTACT: 5565-AT
Connector type	BOARD CONNECTOR
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	43588
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Termination type	SOLDER
Total number of contacts	20
UL Flammability Code	94V-2
Base Number Matches	1

Preview

Download Datasheet

View All

5566-2013 Related Products

	5566-2013	5566-2413-210	5566-186-210	5566-1812-210	5566-206	5566-246-210	5566-182	5566-1811	5566-2012
Description	Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 24 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 18 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 18 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 24 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 18 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 18 Contact(s), 2 Row(s), Female, Straight, Solder Terminal	Board Connector, 20 Contact(s), 2 Row(s), Female, Straight, Solder Terminal
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Other features	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACTS: 5565-AT; 43297-2108	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACT: 5565-AT	COMPATIBLE CONTACTS: 5565-AT; 43297-2108
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	43588	43588	43588	43588	43588	43588	43588	43588	43588
Mixed contacts	NO	NO	NO	NO	NO	NO	NO	NO	NO
Installation method	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	2	2	2	2	2	2	2	2	2
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	20	24	18	18	20	24	18	18	20
UL Flammability Code	94V-2	94V-0	94V-0	94V-0	94V-2	94V-0	94V-2	94V-2	94V-2
Maker	Molex	-	Molex	Molex	Molex	Molex	Molex	Molex	Molex
Base Number Matches	1	1	1	1	1	1	-	-	-
