SCMS5D25
SMD POWER INDUCTORS
XXX
MARKING
●
Features
1. Magnetically shielded construction – Low EMI
2 Excellent Power Density
3 Engineered to Provide High Efficiency
ELECTRICAL CHARACTERISTICS
Part Number
Inductance
(uH)
(1)
Test
DC Resistance
Frequency
(Ω
MAX)
(2)
Saturation Temperature
(3)
(4)
Current
Current
(A)
(A)
10000
BC S5D I
Inductance decrease
cur r ent
M 25
SCMS5D25
nduct ance decr ease by
by current
SCMS5D25-R50
SCMS5D25-R87
SCMS5D25-1R2
SCMS5D25-1R8
SCMS5D25-2R2
SCMS5D25-3R3
SCMS5D25-4R7
SCMS5D25-6R8
SCMS5D25-8R2
SCMS5D25-100
SCMS5D25-150
SCMS5D25-220
SCMS5D25-330
SCMS5D25-470
SCMS5D25-680
SCMS5D25-820
SCMS5D25-101
SCMS5D25-151
SCMS5D25-221
SCMS5D25-331
SCMS5D25-471
SCMS5D25-681
SCMS5D25-821
SCMS5D25-102
0.50
0.87
1.2
1.8
2.2
3.3
4.7
6.8
8.2
10
15
22
33
47
68
82
100
150
220
330
470
680
820
1000
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
19m
23m
26m
30m
34m
42m
56m
70m
90m
0.12
0.13
0.19
0.33
0.36
0.57
0.79
0.82
1.30
2.10
3.12
4.70
8.10
8.65
9.72
4.9
3.6
3.2
2.5
2.2
1.8
1.5
1.25
1.18
1.05
0.93
0.77
0.63
0.49
0.41
0.38
0.35
0.28
0.22
0.20
0.16
0.12
0.11
0.10
5.60
5.00
4.50
3.60
3.24
2.46
2.21
1.98
1.78
1.60
1.44
1.29
1.04
0.93
0.75
0.67
0.58
0.45
0.40
0.32
0.27
0.19
0.18
0.17
1000
102
Inductance (µH)
)
I nduct ance( uH
100
330
10
1
R
50
0. 1
1
10
D cur r ent ( m
C
A)
DC current (mA)
100
1000
10000
BC S5D
Temperature rise
cur r ent
M 25
per
SCMS5D25
Tem at ur e r i se by
by current
80
Temperature
e i se
Tem at ur
rise
r
°C
℃
per
70
60
50
40
30
20
10
0
1000
2000
3000
4000
5000
6000
7000
8000
9000
10000
102
330
R
50
D cur r
current (mA)
C
DC
ent ( m
A)
(1).
Inductance tolerance for 0.5uH~8.2uH:
±30%,
for 10uH~1000uH:
±20%.
Tested at 0.25V, 0ADC and 25℃
(2). DCR measured at 25℃.
(3). The DC current at which the inductance decreases by 30% from its initial value.
(4). The DC current that results in a 40℃ temperature rise from 25℃ambient.
Click here for
QUANTITY PER REEL & PACKING INFORMATION
Custom versions available upon request.
www.signaltransformer.com
©
2011 Signal Transformer –Specification subject to change without notice. 07.11
500 Bayview Avenue, Inwood, NY 11096
Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
