SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Alchip
TM
Standard, 85℃
-
・φ4
through
φ18
case sizes are fully lined up
・Endurance
: 2,000 hours at 85℃
・Suitable
to fit for downsized equipment
・Solvent
resistant type except 100 to 450V
dc
(see PRECAUTIONS AND GUIDELINES)
・RoHS2
Compliant
MVA
Series
MVA
105℃
MVE
◆SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Characteristics
-40 to +85℃
4 to 450V
dc
(at 20℃, 120Hz)
±20%
(M)
Rated voltage (V
dc
)
4 to 100V
160 to 450V
-
D55 to JA0
I=0.01CV or 3μA, whichever is greater.(after 2 minutes)
KE0 to MN0
I=0.03CV or 4μA, whichever is greater.(after 1 minute)
I=0.04CV+100μA max.(after 1 minute)
Where, I : Max. leakage current (μA), C : Nominal capacitance (μF), V : Rated voltage (V)
(at 20℃)
Dissipation Factor
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
(tanδ)
D55 to JA0 0.42 0.35 0.30 0.26 0.16 0.14 0.12 0.12 0.12
-
-
tanδ (Max.)
KE0 to MN0 -
0.38 0.34 0.30 0.26 0.22 0.18 0.14 0.10
0.20
0.25
When nominal capacitance exceeds 1,000μF, add 0.02 to the value above for each 1,000μF increase.
(at 20℃, 120Hz)
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
Low Temperature
Characteristics
Z(-25℃)/Z(+20℃)
7
4
3
2
2
2
2
2
3
-
-
(Max. Impedance Ratio)
D55 to JA0
Z(-40℃)/Z(+20℃)
17
10
8
6
4
3
3
3
4
-
-
Z(-25℃)/Z(+20℃)
-
5
4
3
2
2
2
2
2
3
6
KE0 to MN0
Z(-40℃)/Z(+20℃)
-
12
10
8
5
4
3
3
3
6
10
(at 120Hz)
Endurance
The following specifications shall be satisfied when the capacitors are restored to 20℃ after the rated voltage is applied for 2,000 hours
at 85℃.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage (V
dc
)
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦±30%
of the initial value
≦±20%
of the initial value
D.F. (tanδ)
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
Shelf Life
The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1,000 hours at 85℃ without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦±30%
of the initial value
≦±20%
of the initial value
D.F. (tanδ)
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
◆DIMENSIONS
[mm]
●
Terminal Code :
●
Size code : D55
Vent
(Except D55 to HA0)
φD
±
0.5
B
±
0.2
A
to MN0
W
●
Terminal
●
Size
Vent
φD
±
0.5
Code : G (Vibration resistant structure)
code : LH0 to MN0
Size code
0.3max.
W
D55
E55
F55
F80
HA0
JA0
KE0
KG5
LH0
LN0
MH0
MN0
0.3max.
L
±
0.3(Note)
A
±
0.2
L
±
0.5
A
±
0.2
Note : L±0.5 for HA0 to MN0
: Dummy terminals
◆MARKING
D55 to JA0
EX) 16V47µF
7hA
D
4
5
6.3
6.3
8
10
12.5
12.5
16
16
18
18
L
5.2
5.2
5.2
7.7
10.0
10.0
13.5
16.0
16.5
21.5
16.5
21.5
A
4.3
5.3
6.6
6.6
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
B
4.3
5.3
6.6
6.6
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
C
5.1
5.9
7.2
7.2
9.0
11.0
13.7
13.7
18.0
18.0
20.0
20.0
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
P
1.0
1.4
1.9
1.9
3.1
4.5
4.2
4.2
6.5
6.5
6.5
6.5
P
C
±
0.2
B
±
0.2
47
16V
KE0 to HN0
EX) 25V1,000µF
1000
25V
0V
MVA
P
C
±
0.2
◆RATED
RIPPLE CURRENT MULTIPLIERS
・Frequency
Multipliers
Size code
D55 to JA0
Capacitance(µF)
Frequency(Hz)
◆PART
NUMBERING SYSTEM
E MV A
AAA A AA AAA
M
AAA N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0µF:1R0,100µF:101)
Taping·Tray code
Terminal code (A, G)
Voltage code (ex. 6.3V:6R3,100V:101,450V:451)
Series code
Category
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
KE0 to MN0
1.0
2.2 to 10
22 to 1,500
4.7
10 to 68
100 to 1,000
2,200 to 10,000
120
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1k
1.50
1.30
1.05
1.75
1.50
1.30
1.05
10k
1.75
1.40
1.08
2.30
1.75
1.40
1.08
100k
1.80
1.50
1.08
2.50
1.80
1.50
1.08
The endurance of capacitors is reduced with internal
heating produced by ripple current at the rate of halving
the lifetime with every 5℃ rise.
When long life performance is required in actual use, the
rms ripple current has to be reduced.
Please refer to "Product code guide (surface mount type)"
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
CAT. No. E1001S
