FEATURES
Multiple Case Sizes
-
High Voltage
–
High Current
APPLICATIONS
Operating Temperature
Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
WVDC
Dissipation
tan δ
Factor
(120 Hz)
Leakage Current
@20°C, Rated WVDC
applied
WVDC
Impedance
Ratio
(120 Hz)
-25°C/+20°C
-40°C/+20°C
Filtering
–
Switching Power Supplies
-40°C to +85°C (10VDC to 250VDC)
-25°C to +85°C (350VDC to 500VDC)
+20% at 120 Hz, 20°C
10
13
10
.55
16
20
16
.5
25
32
25
.45
35
44
35
.4
50
63
50
.35
63
79
63
.3
80
100
80
.25
100
120
100
.2
160
200
160
.15
200
250
200
.15
250
300
250
.15
350
400
350
.15
400
450
400
.15
450
500
450
.2
500
550
500
.2
For capacitance values above 33000μF
add the following to the Dissipation factors values above
(capacitance-33000 μF)*0.1
10000 μF
Time
10
4
15
16
4
15
25
4
15
35
4
15
50
4
15
63
4
15
80
4
15
100
4
15
5 Minutes
3√CV
160
3
15
200
3
15
250
3
15
350
3
-
400
8
-
450
8
-
500
8
-
2000 hours with rated voltage applied at 85°C with full rated ripple current applied
Load Life
Capacitance Change
Dissipation Factor
Leakage Current
Capacitance Change
Dissipation Factor
<20% of initial measured value
<200% of maximum specified value
<100% of maximum specified value
1000 hours at 85°C with no voltage applied
Shelf Life
<20% of initial measured value
<200% of maximum specified value
Ripple Current
Multipliers
Leakage Current
<100% of maximum specified value
Frequency (Hz)
WVDC
60
120
1k
10k
10 to 100
0.9
1.0
1.15
1.25
160 to 250
0.8
1.0
1.15
1.47
350 to 500
0.8
1.0
1.15
1.47
.
Feb-17
