www.murata-ps.com
4700S Series
Shielded Surface Mount Power Inductors
SELECTION GUIDE
Inductance
(10kHz, 100mV
AC
)
Order Code
±20%
DC Current
1
DC Resistance
Max.
A
Max.
mΩ
SRF
Typ.
MHz
Q Factor
Typ.
@ f (MHz)
Nom.
μH
Q
FEATURES
RoHS compliant
1.0μH to 1.0mH
Up to 10A I
DC
Bobbin format
Surface mount
Integral EMI shield
Compact size
Tape and reel packaging
UL 94V-0 materials
J-STD-020-C reflow
471R0SC
472R2SC
473R3SC
474R7SC
476R8SC
47100SC
47150SC
47220SC
47330SC
47470SC
47680SC
47101SC
47151SC
47221SC
47331SC
47471SC
47681SC
47102SC
1.0 (±30%)
2.2 (±30%)
3.3 (±30%)
4.7 (±30%)
6.8 (±30%)
10
15
22
33
47
68
100
150
220
330
470
680
1000
10.0
7.0
6.4
5.8
4.6
3.8
3.2
2.7
2.2
1.9
1.6
1.3
1.1
0.8
0.7
0.58
0.48
0.40
4.8
8.5
11.1
16.4
26.9
32.3
46.5
62.9
91.1
168
210
267
410
629
940
1330
1780
2540
79
44
36
34
24
22
18
14
13
11
9
8
7
6
5
5
4
4
24
24
25
25
24
22
29
29
23
23
23
20
19
20
21
23
17
17
1
1
1
1
1
1
1
1
1
1
1
0.8
0.8
0.8
0.8
0.8
0.8
0.8
DESCRIPTION
The 4700S series is a range of bobbin-wound,
surface-mount inductors designed for use in
switching power supply, and power line filter
circuits. The parts are suitable for any application
requiring a high saturation current in a low-profile
package. The devices have an integral ferrite
shield to reduce EMI.
PIN CONNECTIONS
(TOP VIEW)
MECHANICAL DIMENSIONS
12.20±0.30
(0.480±0.012)
7.60±0.5
(0.299±0.02)
47XXXSC
XYYWW
12.20±0.30
(0.480±0.012)
5.0±0.3
(0.197±0.012)
2
1
Recommended Footprint Details
5.00 (0.197) Max.
2.9
(0.114)
5.00 (0.197)
7.00
(0.276)
12.80 (0.504)
1
2
Dot signifies the innermost turn of the winding.
All dimensions in mm (inches). Package weight: 2.4g Typ.
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
Storage temperature range
-40ºC to 85ºC
-40ºC to 125ºC
SOLDERING INFORMATION
2
Peak reflow solder temperature
Pin finish
For full details go to
www.murata-ps.com/rohs
245˚C
Tin
Specifications typical at T
A
= 25°C
1 Maximum DC current occurs when either the inductance falls to 75% of its nominal value or when its temperature rise reaches 40°C,
whichever is sooner.
2 For further information, please visit www.murata-ps.com/rohs
www.murata-ps.com/support
KMP_4700SC_C01
Page 1 of 3
4700S Series
Shielded Surface Mount Power Inductors
INDUCTANCE Vs CURRENT
10000
1000
1mH
Inductance, L (μH)
100
100μH
10μH
10
1
1μH
0.1
0.001
0.01
0.1
1
10
100
Current, I
DC
(A)
TEMPERATURE Vs CURRENT
60
1mH
Temperature rise above ambient, t (ºC)
50
100μH
10μH
1μH
40
30
20
10
0
0
2
4
6
8
10
12
14
Current, I
DC
(A)
INDUCTANCE Vs FREQUENCY
10000
1mH
1000
Inductance, L (μH)
100μH
100
10μH
10
1μH
1
0.1
10
100
1000
10000
Frequency, (kHz)
www.murata-ps.com/support
KMP_4700SC_C01
Page 2 of 3
4700S Series
Shielded Surface Mount Power Inductors
TAPE & REEL SPECIFICATIONS
REEL OUTLINE DIMENSIONS
Ø382 [15.039] Max.
60 [2.36] Min.
13.50 0.531
Ø
12.80 0.504
Leader Section
400 [15.748] Min.
100 [3.937]
Min.
23.9-27.4
[0.94-1.08]*
Ø
1.50 [0.059] Min.
30.4
[1.197]
Max.
†
Goods
Enclosure
Section
24.4 [0.96]†
+2 [0.079]
-0 [0]
Trailer Section
160 [6.299] Min.
All dimensions in mm (inches)
* Includes flange distortion at outer edge
† Measured at hub
Ø20.20 [Ø0.795] Min.
TAPE OUTLINE DIMENSIONS
4.00 (0.157)
1.75 (0.069)
2.00 (0.079)
Ø1.50 +0.10 (Ø0.059 +0.004 )
-0.000
-0.00
11.5
(0.453)
24.0
+0.30
-0.10
(0.945
+0.012
)
-0.004
47XXXSC
XYYWW
0.60 (0.024) Max.
22.3 (0.876)
Min.
5.2 (0.205)
All dimensions in mm (inches)
16.0 (0.630)
DIRECTION OF UNREELING
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
ISO 9001 and 14001 REGISTERED
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2018 Murata Power Solutions, Inc.
www.murata-ps.com/support
KMP_4700SC_C01
Page 3 of 3
