AMPMODU Interconnection System
Breakaway Surface Mount Headers—Unshrouded
PageHead_12_HelvCdBd
(Continued)
Double-Row, .100 x .100 [2.54 x 2.54] Centerline
.025 [0.64] Square
Straight Post
A
B
.100
Typ.
[2.54]
.192
[4.88]
.100
[2.54]
Material and Finish
Housing
— Black thermoplastic, 94V-0
rated
Posts
— Phosphor bronze, plated as
follows:
Plating A
— Duplex plated .000030
[0.00076] gold on contact area,
.000100-.000200 [0.00254-0.00508]
tin on solder area, with entire post
underplated .000050 [0.00127] nickel
Plating B
— .000100-.000200
[0.00254-0.00508] tin over .000050
[0.00127] nickel entire post
Surface Mount
Breakaway Headers
D
Ref.
(Contact Area)
C
.090
[2.29]
.025
[0.64]
.042
[1.07]
Typ.
B
.100
Typ.
[2.54]
.140±.003
[3.56±0.08]
.292
[7.42]
.063
[1.60]
.050
[1.27]
Related Product Data
Mateable Receptacles
—
Refer to Mating Post Selection Guide —
page 90
.345
[8.76]
.205
[5.21]
.065
[1.65]
.050±.003
[1.27±0.08]
5
No. of
Pos.
4
6
8
10
12
14
16
18
20
22
24
26
28
30
Recommended Etched Circuit Layout
(Using .008 [0.20] thick stencil)
Dimensions
A
.184
[4.67]
.284
[7.21]
.384
[9.75]
.484
[12.29]
.584
[14.83]
.684
[17.37]
.784
[19.91]
.884
[22.45]
.984
[24.99]
1.084
[27.53]
1.184
[30.07]
1.284
[32.61]
1.384
[35.15]
1.484
[37.69]
B
.100
[2.54]
.200
[5.08]
.300
[7.62]
.400
[10.16]
.500
[12.70]
.600
[15.24]
.700
[17.78]
.800
[20.32]
.900
[22.86]
1.000
[25.40]
1.100
[27.94]
1.200
[30.48]
1.300
[33.02]
1.400
[35.56]
C = .230 [5.84]
D = .185 [4.70]
Post Plating/Part Nos.
Plating A
Plating B
5-146130-1
5-146134-1
5-146130-2
5-146134-2
5-146130-3
5-146134-3
5-146130-4
1-146134-7
5-146130-5
5-146134-5
5-146130-6
5-146134-6
5-146130-7
1-146134-9
5-146130-8
5-146134-8
5-146130-9
5-146134-9
6-146130-0
6-146134-0
6-146130-1
6-146134-1
6-146130-2
6-146134-2
6-146130-3
6-146134-3
6-146130-4
2-146134-1
C = .320 [8.13]
D = .200 [5.08]
Post Plating/Part Nos.
Plating A
Plating B
5-146131-1
5-146135-1
5-146131-2
1-146135-6
5-146131-3
5-146135-3
5-146131-4
5-146135-4
5-146131-5
5-146135-5
5-146131-6
5-146135-6
5-146131-7
5-146135-7
5-146131-8
5-146135-8
5-146131-9
5-146135-9
6-146131-0
6-146135-0
6-146131-1
6-146135-1
6-146131-2
6-146135-2
6-146131-3
6-146135-3
6-146131-4
6-146135-4
Note:
All part numbers are RoHS compliant.
110
Catalog 1307819
Revised 8-08
www.tycoelectronics.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
