1. Permanent device damage may occur if absolute maximum ratings are exceeded. This is a stress rating only and functional operation is not implied
at conditions other than those detailed in the operational sections of this data sheet. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.
3. Package thermal resistance assumes exposed pad is soldered (or equivalent) to the device's most negative potential on the PCB.
JB
and
JA
values
are determined for a 4-layer board in still-air number, unless otherwise stated.
4. The circuit is designed to meet the DC specifications shown in the above table after thermal equilibrium has been established.
5. Due to the internal termination (see "Input Stage" section) the input current depends on the applied voltages at IN, /IN and VT inputs. Do not apply a
combination of voltages that causes the input current to exceed the maximum limit!
Oct. 1, 2013
4
M9999-032609-A
hbwhelp@micrel.com
or (408) 955-1690
Micrel, Inc.
SY89833AL
LVDS Outputs DC Electrical Characteristics
(6)
V
CC
= 3.3V ±10%, R
L
=
100Ω across the output, T
A
=
–40°C
to +85°C, unless otherwise noted.
Symbol
V
OUT
V
DIFF_OUT
V
OCM
V
OCM
Parameter
Output Voltage Swing
Differential Output Voltage Swing
Output Common Mode Voltage
Change in Common Mode Voltage
Condition
See Figure 2c.
See Figure 2d.
Min
250
500
1.125
–50
Typ
325
650
1.275
50
Max
Units
mV
mV
V
mV
LVTTL/CMOS DC Electrical Characteristics
(6)
V
CC
= 3.3V ±10%, T
A
=
–40°C
to +85°C, unless otherwise noted.
Symbol
V
IH
V
IL
I
IH
I
IL
Parameter
Input HIGH Voltage
Input LOW Voltage
Input HIGH Current
Input LOW Current
Condition
Min
2.0
0
–125
–300
Typ
Max
V
CC
0.8
30
Units
V
V
μA
μA
Notes:
6. The circuit is designed to meet the DC specifications shown in the above table after thermal equilibrium has been established.
