BAW27
www.vishay.com
Vishay Semiconductors
Small Signal Switching Diode
FEATURES
• Silicon epitaxial planar diode
• Low forward voltage drop
• High forward current capability
• AEC-Q101 qualified
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
• High speed switch and general purpose use in computer
and industrial applications
MECHANICAL DATA
Case:
DO-35 (DO-204AH)
Weight:
approx. 125 mg
Cathode band color:
black
Packaging codes / options:
TR/10K per 13" reel (52 mm tape), 50K/box
TAP/10K per ammopack (52 mm tape), 50K/box
PARTS TABLE
PART
BAW27
ORDERING CODE
BAW27-TR or BAW27-TAP
TYPE MARKING
BAW27
CIRCUIT CONFIGURATION
Single
REMARKS
Tape and reel / ammopack
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Repetitive peak reverse voltage
Reverse voltage
Peak forward surge current
Forward continuous current
Average forward current
Power dissipation
V
R
= 0
l = 4 mm, T
L
= 45 °C
l = 4 mm, T
L
≤
25 °C
t
p
= 1 μs
TEST CONDITION
SYMBOL
V
RRM
V
R
I
FSM
I
F
I
F(AV)
P
tot
P
tot
VALUE
75
60
4
600
300
440
500
UNIT
V
V
A
mA
mA
mW
mW
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
l = 4 mm, T
L
= constant
SYMBOL
R
thJA
T
j
T
stg
VALUE
350
175
-65 to +175
UNIT
K/W
°C
°C
Rev. 1.8, 13-Jul-17
Document Number: 85548
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAW27
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 10 mA
I
F
= 50 mA
I
F
= 200 mA
I
F
= 400 mA
V
R
= 60 V
V
R
= 60 V, T
j
= 100 °C
I
R
= 5 μA, t
p
/T = 0.01,
t
p
= 0.3 ms
V
R
= 0 V, f = 1 MHz,
V
HF
= 50 mV
I
F
= I
R
= 10 mA,
i
R
= 0.1 x I
R
SYMBOL
V
F
V
F
V
F
V
F
I
R
I
R
V
(BR)
C
D
t
rr
75
4
6
MIN.
TYP.
0.670
800
950
1120
MAX.
0.750
850
1000
1250
100
50
UNIT
V
mV
mV
mV
nA
μA
V
pF
ns
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse current
Breakdown voltage
Diode capacitance
Reverse recovery time
PACKAGE DIMENSIONS
in millimeters (inches):
DO-35 (DO-204AH)
Cathode Identification
Ø 0.6 max. [0.024]
Ø 0.4 min. [0.015]
1.7 [0.067]
26 min. [1.024]
3.9 max. [0.154]
3.1 min. [0.120]
26 min. [1.024]
Rev. 6 - Date: 19. December 2011
Document no.: SB-V-3906.04-031(4)
94 9366
Rev. 1.8, 13-Jul-17
Document Number: 85548
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1.3 [0.050]
