Schottky Barrier Rectifier
DST2045C, 2x10A, 45V, TO-220AB, Common Cathode
DST2045C
Description
RoHS
Pb
Littelfuse DST series Ultra Low V
F
Schottky Barrier
Rectifier is designed to meet the general requirements
of commercial and industry applications by providing high
temperature, low leakage and lower V
F
products.
It is suitable for high frequency switching mode power
supply, free-wheeling diodes and polarity protection
diodes.
Features
Pin out
Heat sink
Heat sink
• Ultra low forward voltage
drop
• High frequency operation
• High junction
temperature capability
Common
Cathode
• Guard ring for enhanced
ruggedness and long
term reliability
• Common cathode
configuration in TO-
220AB package
Common
Cathode
Anode
1
Anode
3
Pinout 1
D2-PAK & D-PAK
Common Cathode
Anode Common Anode
Cathode
1
2
3
3
Applications
Anode Common Anode
2
Cathode
1
Pinout 2
TO-220AB
Common Cathode
• Switching mode power
supply
• Free-Wheeling diodes
• Polarity Protection Diodes
Pinout 3
• DC/DC converters
ITO-220AB
Common Cathode
Heat sink
Cathode
Maximum Ratings
Cathode
Common
Cathode
Anode
1
2
3
Pinout 4
Peak Inverse Voltage
ITO-220AB
Common Anode
Average Forward Current
Parameters
Cathode
1
Symbol
V
RWM
Anode
2
Test Conditions
-
50% duty cycle @T
C
=80°C
rectangular wave form
8.3 ms, half Sine pulse
Max
45
10 (per leg)
20 (total device)
150
Unit
V
A
A
Pinout 5
I
F(AV)
TO-220AC
I
FSM
Peak One Cycle Non-Repetitive Surge
Current (per leg)
Electrical Characteristics
Parameters
Forward Voltage Drop (per leg) *
Reverse Current (per leg) *
*
Pulse Width < 300μs, Duty Cycle <2%
Symbol
V
F1
V
F2
I
R1
I
R2
Test Conditions
@10A, Pulse, T
J
= 25 °C
@10A, Pulse, T
J
= 125 °C
@V
R
= rated V
R
T
J
= 25 °C
@V
R
= rated V
R
T
J
= 125 °C
Max
0.58
0.52
2
30
Unit
V
mA
©2016 Littelfuse, Inc
Specifications are subject to change without notice.
Revised:02/03/16
Schottky Barrier Rectifier
DST2045C, 2x10A, 45V, TO-220AB, Common Cathode
Thermal-Mechanical Specifications
Parameters
Junction Temperature
Storage Temperature
Thermal Resistance Junction to
Case (per leg)
Approximate Weight
Case Style
Symbol
T
J
T
stg
R
thJC
wt
TO-220AB
DC operation
Test Conditions
Max
-55 to +150
-55 to +150
3.0
1.8
Unit
°C
°C
°C/W
g
Figure 1: Typical Forward Characteristics
Figure 2: Typical Reverse Characteristics
ºC
ºC
ºC
ºC
Figure 3: Typical Junction Capacitance
ºC
©2016 Littelfuse, Inc
Specifications are subject to change without notice.
Revised:02/03/16
Schottky Barrier Rectifier
DST2045C, 2x10A, 45V, TO-220AB, Common Cathode
Dimensions- TO-220AB
Symbol
A
A1
A2
b
b1
c
D
D1
E
e
e1
H1
L
L1
Millimeters
Min
3.56
0.51
2.03
0.38
1.14
0.31*
14.22
8.38
9.65
2.54
4.98*
5.84
12.70
-
3.53
2.54
Max
4.83
1.40
2.92
1.02
1.78
0.61
16.51
9.15*
10.67
-
-
6.86
14.73
6.35
4.09
3.43
ø
P
Q
Footnote *: The spec. does not comply with JEDEC spec.
Packing Options
Part Number
DST2045C
Marking
DST2045C
Packing Mode
50pcs / Tube
M.O.Q
1000
Part Numbering and Marking System
Tube Specification
DST2045C
6
LF YYWWL
DST
20
45
C
LF
YY
WW
L
= Device Type
= Forward Current (20A)
= Reverse Voltage (45V)
= Configuration
= Littelfuse
= Year
= Week
= Lot Number
©2016 Littelfuse, Inc
Specifications are subject to change without notice.
Revised:02/03/16
