BYV29-400
Ultrafast power diode
Rev. 3 — 29 May 2012
Product data sheet
1. Product profile
1.1 General description
Ultrafast power diode in a SOD59 (2-lead TO-220AC) plastic package.
1.2 Features and benefits
Fast switching
High thermal cycling performance
Low forward volt drop
Low thermal resistance
Soft recovery minimizes
power-consuming oscillations
1.3 Applications
Discontinuous Current Mode (DCM)
Power Factor Correction (PFC)
Output rectifiers in high-frequency
switched-mode power supplies
1.4 Quick reference data
Table 1.
Symbol
V
RRM
I
F(AV)
Quick reference data
Parameter
repetitive peak reverse voltage
average forward current
square-wave pulse;
δ
= 0.5 ;
T
mb
≤
123 °C; see
Figure 1;
see
Figure 2
I
F
= 8 A; T
j
= 150 °C; see
Figure 4
I
F
= 1 A; V
R
= 30 V; dI
F
/dt = 100 A/s;
T
j
= 25 °C; see
Figure 7;
see
Figure 5
Conditions
Min
-
-
Typ
-
-
Max
400
9
Unit
V
A
Static characteristics
V
F
t
rr
forward voltage
reverse recovery time
-
-
0.9
50
1.03
60
V
ns
Dynamic characteristics
NXP Semiconductors
BYV29-400
Ultrafast power diode
2. Pinning information
Table 2.
Pin
1
2
mb
Pinning information
Symbol Description
K
A
mb
cathode
anode
mounting base; cathode
mb
K
A
001aaa020
Simplified outline
Graphic symbol
1
2
SOD59 (TO-220AC)
3. Ordering information
Table 3.
Ordering information
Package
Name
BYV29-400
TO-220AC
Description
plastic single-ended package; heatsink mounted; 1 mounting
hole; 2-lead TO-220AC
Version
SOD59
Type number
4. Limiting values
Table 4.
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FRM
I
FSM
T
stg
T
j
Limiting values
Parameter
repetitive peak reverse voltage
crest working reverse voltage
reverse voltage
average forward current
repetitive peak forward current
non-repetitive peak forward
current
storage temperature
junction temperature
DC
square-wave pulse;
δ
= 0.5 ; T
mb
≤
123 °C;
see
Figure 1;
see
Figure 2
square-wave pulse;
δ
= 0.5 ; t
p
= 25 µs;
T
mb
≤
123 °C
sine-wave pulse; t
p
= 10 ms; T
j(init)
= 25 °C
sine-wave pulse; t
p
= 8.3 ms; T
j(init)
= 25 °C
Conditions
Min
-
-
-
-
-
-
-
-40
-
Max
400
400
400
9
18
100
110
150
150
Unit
V
V
V
A
A
A
A
°C
°C
In accordance with the Absolute Maximum Rating System (IEC 60134).
BYV29-400
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 3 — 29 May 2012
2 of 11
NXP Semiconductors
BYV29-400
Ultrafast power diode
16
P
tot
(W)
12
0.5
003aaj587
12
P
tot
(W)
2.2
8
2.8
4.0
003aaj588
δ=1
a = 1.57
1.9
0.2
8
0.1
4
4
0
0
4
8
12
I
F(AV)
(A)
16
0
0
2
4
6
8
10
I
F(AV)
(A)
Fig 1.
Forward power dissipation as a function of
average forward current; square waveform;
maximum values
Fig 2.
Forward power dissipation as a function of
average forward current; sinusoidal waveform;
maximum values
BYV29-400
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 3 — 29 May 2012
3 of 11
NXP Semiconductors
BYV29-400
Ultrafast power diode
5. Thermal characteristics
Table 5.
Symbol
R
th(j-mb)
R
th(j-a)
Thermal characteristics
Parameter
thermal resistance from junction to mounting base
thermal resistance from junction to ambient free air
Conditions
see
Figure 3
in free air
Min
-
-
Typ
-
60
Max
2.5
-
Unit
K/W
K/W
10
Z
th(j-mb)
(K/W)
1
001aag913
10
−1
P
δ
=
t
p
T
10
−2
t
p
t
T
10
−3
10
−6
10
−5
10
−4
10
−3
10
−2
10
−1
1
10
t
p
(s)
Fig 3.
Transient thermal impedance from junction to mounting base as a function of pulse width
BYV29-400
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 3 — 29 May 2012
4 of 11
