BSS123ATC Overview

MOSFET N-Chnl 100V

BSS123ATC Parametric

Parameter Name	Attribute value
Maker	Diodes Incorporated
package instruction	SMALL OUTLINE, R-PDSO-G3
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SINGLE
Minimum drain-source breakdown voltage	100 V
Maximum drain current (ID)	0.17 A
Maximum drain-source on-resistance	5 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	N-CHANNEL
Certification status	Not Qualified
surface mount	YES
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

BSS123

N-CHANNEL ENHANCEMENT MODE MOSFET

Product Summary

DSS

100V

DS(ON)

6.0Ω @ V

= 10V

= +25°

0.17A

Features and Benefits



Low Gate Threshold Voltage

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

High Drain-Source Voltage Rating

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

PPAP Capable (Note 4)

ADVANCE INFORMATION

Description and Applications

These N-Channel enhancement mode field effect transistors are

produced using DIODES proprietary, high density, uses advanced

trench technology. These products have been designed to minimize

on-state resistance while provide rugged, reliable, and fast switching

performance. These products are particularly suited for low voltage,

low current applications such as:



Small Servo Motor Control

Power MOSFET Gate Drivers

Switching Applications

Mechanical Data



Case: SOT23

Case Material: Molded Plastic. UL Flammability Classification

Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Matte Tin Finish Annealed over Alloy 42 Leadframe

(Lead Free Plating). Solderable per MIL-STD-202, Method 208

Terminal Connections: See Diagram

Weight: 0.008 grams (Approximate)

SOT23

Top View

Equivalent Circuit

Top View

Ordering Information

(Note 5)

Part Number

BSS123-7-F

BSS123Q-13

BSS123Q-7

Notes:

Qualification

Commercial

Automotive

Case

SOT23

Packaging

3,000 / Tape & Reel

10,000 / Tape & Reel

3,000 / Tape & Reel

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the

same, except where specified. For more information, please refer to http://www.diodes.com/product_compliance_definitions.html.

5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

K23 = Product Type Marking Code

YM = Date Code Marking

Y or = Year (ex: C = 2015)

M = Month (ex: 9 = September)

Date Code Key

Year

Code

Month

Code

2006

Jan

2007

Feb

2008

Mar

2009

Apr

2010

May

2011

Jun

2012

Jul

2013

Aug

2014

Sep

2015

Oct

2016

Nov

2017

Dec

March 2016

BSS123

Document number: DS30366 Rev. 20 - 2

1 of 7

www.diodes.com
