BYW72-TAP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BYW72-TAP

BYW72-TAP: DescriptionRectifiers 3.0 Amp 200 Volt 100 Amp IFSM; CategoryDiscrete semiconductor diode; File Size114KB，4 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BYW72-TAP Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BYW72-TAP	-	-	View	Buy Now

BYW72-TAP Overview

Rectifiers 3.0 Amp 200 Volt 100 Amp IFSM

BYW72-TAP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	HALOGEN FREE AND ROHS COMPLIANT, HERMETIC SEALED, GLASS PACKAGE-2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
application	FAST SOFT RECOVERY
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
JESD-30 code	E-LALF-W2
JESD-609 code	e2
Maximum non-repetitive peak forward current	100 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-55 °C
Maximum output current	3 A
Package body material	GLASS
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	260
Maximum repetitive peak reverse voltage	200 V
Maximum reverse current	5 µA
Maximum reverse recovery time	0.2 µs
surface mount	NO
technology	AVALANCHE
Terminal surface	Tin/Silver (Sn96.5Ag3.5)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	30
Base Number Matches	1

Preview

Download Datasheet

View All

BYW72, BYW73, BYW74, BYW75, BYW76

www.vishay.com

Vishay Semiconductors

Fast Avalanche Sinterglass Diode

FEATURES

• Glass passivated junction

• Hermetically sealed package

• Low reverse current

• Soft recovery characteristics

• Material categorization:



For definitions of compliance please see

www.vishay.com/doc?99912

949588

MECHANICAL DATA

Case:

SOD-64

Terminals:

plated axial leads, solderable per MIL-STD-750,

method 2026

Polarity:

color band denotes cathode end

Mounting position:

any

Weight:

approx. 858 mg

APPLICATIONS

• Fast rectification and switching diode for TV-line output

circuits and switch mode power supply



ORDERING INFORMATION

(Example)

DEVICE NAME

BYW72 or

BYW73

BYW72 or

BYW73

BYW74 or BYW75 or

BYW76

BYW74 or BYW75 or

BYW76

ORDERING CODE

BYW73-TR

BYW73-TAP

BYW76-TR

BYW76-TAP

TAPED UNITS

2500 per 10" tape and reel

2500 per ammopack

2500 per 10" tape and reel

2500 per ammopack

MINIMUM ORDER QUANTITY

12 500

PARTS TABLE

PART

BYW72

BYW73

BYW74

BYW75

BYW76

TYPE DIFFERENTIATION

= 200 V; I

F(AV)

= 3 A

= 300 V; I

F(AV)

= 3 A

= 400 V; I

F(AV)

= 3 A

= 500 V; I

F(AV)

= 3 A

= 600 V; I

F(AV)

= 3 A

PACKAGE

SOD-64

ABSOLUTE MAXIMUM RATINGS

amb

= 25 °C, unless otherwise specified)

PARAMETER

TEST CONDITION

PART

BYW72

BYW73

Reverse voltage = repetitive peak

reverse voltage

See electrical characteristics

BYW74

BYW75

BYW76

Peak forward surge current

Repetitive peak forward current

Average forward current

Non repetitive reverse avalanche

energy

Junction and storage temperature

range

(BR)R

= 0.4 A

= 10 ms, half sine wave

SYMBOL

= V

RRM

= V

RRM

= V

RRM

= V

RRM

= V

RRM

FSM

FRM

F(AV)

= T

stg

VALUE

200

300

400

500

600

100

- 55 to + 175

UNIT

°C

Rev. 1.8, 11-Sep-12
