ZL30157GGG2

Description
Clock Generators & Support Products Pb Free Programmable Timing Platform
Categorysemiconductor    Analog mixed-signal IC
File Size72KB,4 Pages
ManufacturerMicrosemi
Websitehttps://www.microsemi.com
Environmental Compliance
Download Datasheet Parametric View All

ZL30157GGG2 Online Shopping

Suppliers Part Number Price MOQ In stock
ZL30157GGG2 - - View Buy Now

ZL30157GGG2 Overview

Clock Generators & Support Products Pb Free Programmable Timing Platform

ZL30157GGG2 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerMicrosemi
Product CategoryClock Generators & Support Products
RoHSDetails
Factory Pack Quantity168
ZL30157
Two
Channel Universal Clock Translator
Short Form Data Sheet
March 2011
Features
Two independent clock channels
Programmable synthesizers generate any clock-
rate from 1 kHz to 720 MHz
One precision synthesizers generate clocks with
jitter below 0.7 ps RMS for 10 G PHYs
One general purpose synthesizers generate a wide
range of digital bus clocks
Programmable digital PLLs synchronize to any
clock rate from 1 kHz to 720 MHz
Flexible two-stage architecture translates between
arbitrary data rates, line coding rates and FEC
rates
Digital PLLs filter jitter from 14 Hz, 28 Hz, 56 Hz,
112 Hz, 224 Hz, 448 Hz or 896 Hz
Automatic hitless reference switching and digital
holdover on reference fail
Four reference inputs configurable as single ended
or differential
Eight LVPECL outputs and four LVCMOS outputs
Ordering Information
ZL30157GGG
ZL30157GGG2
100 Pin CABGA
100 Pin CABGA*
-40
o
C to +85
o
C
Trays
Trays
*Pb Free Tin/Silver/Copper
Eight outputs configurable as LVCMOS or
LVDS/LVPECL/HCSL
Operates from a single crystal resonator or clock
oscillator
Configurable via SPI/I2C interface
Applications
10 Gigabit line cards
Synchronous Ethernet, 10 GBASE-R and
10 GBASE-W
OTN multiplexers and transponders
SONET/SDH, Fibre Channel, XAUI
ZL30157
Osci
Osco
Master Clock
Clock Generator 0 (Precision)
Div A
Div A
Div B
Synthesizer 0
Fs= Bs
0
*Ks
0
*16*Ms
0
/Ns
0
DPLL0
Fr= Br
0
*Kr
0
*Mr
0
/Nr
0
Div B
Div C
Div C
Div D
Div D
Outputs
4 x LVPECL
LVPECL
4 x LVPECL
LVCMOS
2 x LVCMOS
LVCMOS
2 x LVCMOS
hpdiff0_p/n
hpdiff1_p/n
hpdiff2_p/n
hpdiff3_p/n
hpdiff4_p/n
hpdiff5_p/n
hpdiff6_p/n
hpdiff7_p/n
hpoutclk0
hpoutclk1
hpoutclk2
hpoutclk3
Ref0
Differential /
Single Ended
Differential /
Single Ended
Differential /
Single Ended
Differential /
Single Ended
Ref1
Ref2
DPLL1
Fr= Br
1
*Kr
1
*Mr
1
/Nr
1
Clock Generator 1 (General Purpose)
Div A
Div A
Div B
Div B
Div C
Div C
Div D
Div D
Outputs
Differential /
Single Ended
2 x Differential
Differential /
or 4 x Single
Single Ended
Ended
Differential /
Single Ended
2 x Differential
Differential /
or 4 x Single
Single Ended
Ended
outclk0
outclk1
outclk2
outclk3
outclk4
outclk5
outclk6
outclk7
Ref3
JTAG
JTAG
State Machine
Configuration
and Status
Synthesizer 1
Fs= Bs
1
*Ks
1
*8*Ms
1
/Ns
1
Reference Monitors
pwr_b
GPIO
SPI / I
2
C
Figure 1 - Functional Block Diagram
1
Zarlink Semiconductor Inc.
Zarlink, ZL and the Zarlink Semiconductor logo are trademarks of Zarlink Semiconductor Inc.
Copyright 2011, Zarlink Semiconductor Inc. All Rights Reserved.
