SR2020 thru SR20150
Taiwan Semiconductor
CREAT BY ART
FEATURES
- Low power loss, high efficiency
- Guardring for overvoltage protection
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
Dual Common Cathode Schottky Rectifier
TO-220AB
MECHANICAL DATA
Case:
TO-220AB
Molding compound, UL flammability classification rating 94V-0
Base P/N with suffix "G" on packing code - halogen-free
Base P/N with prefix "H" on packing code - AEC-Q101 qualified
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test,
with prefix "H" on packing code meet JESD 201 class 2 whisker test
Polarity:
As marked
Mounting torque:
5 in-lbs maximum
Weight:
1.8 g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
I
F
=10A
Maximum reverse current @ rated VR
T
J
=25
℃
T
J
=100℃
T
J
=125
℃
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
0.55
0.5
I
R
dV/dt
R
θJC
T
J
T
STG
- 55 to +125
- 55 to +150
15
-
10000
1.0
- 55 to +150
10
SR
2020
20
14
20
SR
2030
30
21
30
SR
2040
40
28
40
SR
2050
50
35
50
20
200
0.70
0.90
0.1
-
5.0
V/μs
O
SR
2060
60
42
60
SR
90
63
90
SR
100
70
100
SR
150
105
150
2090 20100 20150
UNIT
V
V
V
A
A
1.00
V
mA
Voltage rate of change (Rated V
R
)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
C/W
O
O
C
C
Document Number: DS_D1308041
Version: I13
SR2020 thru SR20150
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
SR20xx
AEC-Q101
QUALIFIED
Prefix "H"
PACKING CODE
C0
GREEN COMPOUND
CODE
Suffix "G"
PACKAGE
TO-220AB
PACKING
50 / Tube
Note 1: "xx" defines voltage from 20V (SR2020) to 150V (SR20150)
EXAMPLE
PREFERRED P/N
SR2060 C0
SR2060 C0G
SR2060HC0
PART NO.
SR2060
SR2060
SR2060
H
AEC-Q101
QUALIFIED
PACKING CODE
C0
C0
C0
G
Green compound
AEC-Q101 qualified
GREEN COMPOUND
CODE
DESCRIPTION
RATINGS AND CHARACTERISTICS CURVES
(TA=25℃ unless otherwise noted)
FIG. 1- FORWARD CURRENT DERATING CURVE
SR2050-150
20
15
10
5
0
50
100
CASE TEMPERATURE (
o
C)
150
RESISTIVE OF
INDUCTIVE LOAD
WITH HEATSINK
PEAK FORWARD SURGE CURRENT (A)
AVERAGE FORWARD CURRENT (A)
25
300
250
200
150
100
50
0
1
FIG. 2- MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT PER LEG
8.3ms Single Helf Sine Wave
PER LEG. (JEDEC Method)
SR2020-40
10
NUMBER OF CYCLES AT 60 Hz
100
FIG. 3- TYPICAL FORWARD CHARACTERISTICS
PER LEG
100
SR2050-2060
INSTANTANEOUS FORWARD CURRENT
(A)
SR2020-2040
10
SR2090-20100
INSTANTANEOUS REVERSE CURRENT
(mA)
10
FIG. 4- TYPICAL REVERSE CHARACTERISTICS
PER LEG
TJ=100℃
1
0.1
TJ=25℃
1
SR20150
0.01
0.1
0.2
0.3
0.4
0.5
PULSE WIDTH-300μs
1% DUTY CYCLE
0.6
0.7
0.8
0.9
1.0
0.001
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
INSTANTANEOUS FORWARD VOLTAGE (V)
Document Number: DS_D1308041
Version: I13
SR2020 thru SR20150
Taiwan Semiconductor
FIG. 5- TYPICAL JUNCTION CAPACITANCE
PER LEG
10000
JUNCTION CAPACITANCE (pF)
A
f=1.0MHz
Vsig=50mVp-p
TRANSIENT THERMAL
IMPEDANCE (℃/W)
FIG. 6- TYPICAL TRANSIENT THERMAL IMPEDANCE
PER LEG
100
10
1000
SR2020-40
SR2050-150
1
100
0.1
1
10
100
REVERSE VOLTAGE (V)
0.1
0.01
0.1
1
10
100
T, PULSE DURATION. (sec)
PACKAGE OUTLINE DIMENSIONS
Unit (mm)
Min
-
2.62
2.80
0.68
3.54
14.60
13.19
2.41
4.42
1.14
5.84
2.20
0.35
Max
10.50
3.44
4.20
0.94
4.00
16.00
14.79
2.67
4.76
1.40
6.86
2.80
0.64
Unit (inch)
Min
-
0.103
0.110
0.027
0.139
0.575
0.519
0.095
0.174
0.045
0.230
0.087
0.014
Max
0.413
0.135
0.165
0.037
0.157
0.630
0.582
0.105
0.187
0.055
0.270
0.110
0.025
DIM.
A
B
C
D
E
F
G
H
I
J
K
L
M
MARKING DIAGRAM
P/N
G
YWW
F
= Marking Code
= Green Compound
= Date Code
= Factory Code
Document Number: DS_D1308041
Version: I13
SR2020 thru SR20150
Taiwan Semiconductor
CREAT BY ART
