MC10100FNR2 datasheet, PDF - EEWORLD Datasheet

MC10100FNR2: DescriptionMULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE; Categorylogic logic; File Size505KB，7 Pages; ManufacturerMotorola ( NXP ); Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

MC10100FNR2 Overview

MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE

Parameter Name	Attribute value
Maker	Motorola ( NXP )
package instruction	QCCJ,
Reach Compliance Code	unknow
Other features	STROBED OUTPUTS
series	10K
JESD-30 code	S-PQCC-J20
length	8.965 mm
Logic integrated circuit type	NOR GATE
Number of functions	4
Number of entries	2
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Output characteristics	OPEN-EMITTER
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Maximum supply current (ICC)	29 mA
propagation delay (tpd)	3.3 ns
Certification status	Not Qualified
Maximum seat height	4.57 mm
surface mount	YES
technology	ECL
Temperature level	OTHER
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
width	8.965 mm

	MC10100FNR2	1672	MC10100FN	MC1672	MC10H100FNR2
Description	MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE	MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE	MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE	MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE	MULTICOMP - 1672 - TERMINAL; SPADE/FORK; #8; CRIMP; BLUE
Maker	Motorola ( NXP )	-	Motorola ( NXP )	-	Motorola ( NXP )
package instruction	QCCJ,	-	QCCJ, LDCC20,.4SQ	-	QCCJ,
Reach Compliance Code	unknow	-	unknow	-	unknow
Other features	STROBED OUTPUTS	-	STROBED OUTPUTS	-	STROBED OUTPUTS
series	10K	-	10K	-	10H
JESD-30 code	S-PQCC-J20	-	S-PQCC-J20	-	S-PQCC-J20
length	8.965 mm	-	8.965 mm	-	8.965 mm
Logic integrated circuit type	NOR GATE	-	NOR GATE	-	NOR GATE
Number of functions	4	-	4	-	4
Number of entries	2	-	2	-	2
Number of terminals	20	-	20	-	20
Maximum operating temperature	85 °C	-	85 °C	-	75 °C
Output characteristics	OPEN-EMITTER	-	OPEN-EMITTER	-	OPEN-EMITTER
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	-	PLASTIC/EPOXY
encapsulated code	QCCJ	-	QCCJ	-	QCCJ
Package shape	SQUARE	-	SQUARE	-	SQUARE
Package form	CHIP CARRIER	-	CHIP CARRIER	-	CHIP CARRIER
Maximum supply current (ICC)	29 mA	-	29 mA	-	29 mA
propagation delay (tpd)	3.3 ns	-	3.3 ns	-	1.5 ns
Certification status	Not Qualified	-	Not Qualified	-	Not Qualified
Maximum seat height	4.57 mm	-	4.57 mm	-	4.57 mm
surface mount	YES	-	YES	-	YES
technology	ECL	-	ECL	-	ECL
Temperature level	OTHER	-	OTHER	-	COMMERCIAL EXTENDED
Terminal form	J BEND	-	J BEND	-	J BEND
Terminal pitch	1.27 mm	-	1.27 mm	-	1.27 mm
Terminal location	QUAD	-	QUAD	-	QUAD
width	8.965 mm	-	8.965 mm	-	8.965 mm
