ALUMINUM ELECTROLYTIC CAPACITORS
ULT
Specifications
Chip Type, High Voltage.
High Temperature Range.
Chip type, high voltage and high temperature range.
Load life of 2000 hours at +125°C.
Applicable to automatic mounting machine
using carrier tape.
Compliant to the RoHS directive (2011/65/EU).
ULH
Long Life
ULT
High
Voltage
UUB
Performance Characteristics
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
–40 to +125°C
160 to 500V
1.8 to 33µF
± 20% at 120Hz, 20°C
Rated voltage (V)
–
Rated voltage (V)
tan
δ
(MAX.)
160~450
0.04CV+100(µA)max.(1 minute's at 20°C)
160
0.20
200
0.20
160
6
250
0.25
200
6
400
0.25
250
10
500
0.04CV+200(µA)max.(1 minute's at 20°C)
500
0.30
450
15
500
15
Within ±30% of the initial capacitance value
300% or less than the intial specified value
Less than or equal to the initial specified value
Measurement frequency : 120Hz at 20°C
Tangent of loss angle (tan
δ)
450
0.30
400
10
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
Z–40°C / Z+20°C
ZT / Z20 (MAX.)
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 2000 hours at 125°C.
Capacitance change
tan
δ
Leakage current
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 125°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds,
Within ±10% of the initial capacitance value
Capacitance change
which is maintained at 250°C and then performing voltage
treatment based on JIS C 5101-4 clause 4.1 at 20°C, they
Less than or equal to the initial specified value
tan
δ
shall meet the characteristic requirements listed at right
Less than or equal to the initial specified value
Leakage current
when they are removed from the plate.
Black print on the case top.
Chip Type
(φ8 ,
φ10)
Voltage(2G : 400V)
Series
Lot No.
0.3MAX.
C±0.2
0.5MAX.
Plastic platform
Positive
Type numbering system (Example : 400V 6.8
µ
F)
1
2
3
4
5
6
7
8
9 10
11 12 13 14
U L T 2 G 6 R 8 MN L 1 GS
A±0.2 E A±0.2
Taping code
Configuration
Capacitance tolerance (±20%)
Rated capacitance (6.8µF)
Negative
Rated voltage (400V)
Series name
Type
A2
6.8 2G
LT
φD±0.5
Trade mark
Capacitance
B±0.2
L±1.0
Pressure relief vent
H
(mm)
φD
× L
A
B
C
E
L
H
8 × 10 10 × 10
2.9
3.2
10.3
8.3
10.3
8.3
3.1
4.5
10
10
0.8 to 1.1 0.8 to 1.1
10 × 13.5
3.2
10.3
10.3
4.5
13.5
0.8 to 1.1
Voltage
V
Code
160
2C
200
2D
250
2E
400
2G
450
2W
500
2H
Dimensions
Cap.(µF)
1.8
3.3
3.9
4.7
5.6
6.8
7.5
8.2
10
12
15
18
22
27
33
1R8
3R3
3R9
4R7
5R6
6R8
7R5
8R2
100
120
150
180
220
270
330
V
Code
160
2C
200
2D
250
2E
8
×
10
10
×
10
8
×
10
30
45
50
400
2G
30
45
50
8
×
10
10
×
10
450
2W
20
35
40
8
×
10
10
×
10
500
2H
20
35
40
10
×
13.5
10
×
13.5
8
×
10
10
×
10
10
×
13.5
45
60
65
8
×
10
10
×
10
10
×
13.5
45
60
65
10
×
13.5
10
×
10
10
×
13.5
Case size
φ
D
×
L (mm)
Rated
ripple
Rated ripple current (mArms) at 125°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz or more
1.50
Taping specifications are given in page 23.
Recommended land size, soldering by reflow are given
in page 18, 19.
Please refer to page 3 for the minimum order quantity.
