ECM 2512 SMD Chip Inductor
ECM63T Series
Standard EIA 2512 package
Wire-wound Construction
High ‘Q’, High SRF
Fully Encapsulated
Up to 1.0mH +/-10%
Typical Reel Size 1500pcs
The ECM63T range of surface mount inductor offers uniquely high self-resonant frequencies and ‘Q’
values. The ferrite chip core is totally enclosed within the LCP body of the component offering
excellent reliability and low EMI radiation. Inductance range 220nH ~ 1mH.
COMPONENT OUTLINE
DIMENSIONS (mm)
A
6.30
B
3.20
C
3.20
D
1.80
E
2.50
F
5.00
ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK
Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk
Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to
discontinue any product or make design changes we believe necessary.
Issue 1
ECM 2512 SMD Chip Inductor
ECM
Part
L
(
µ
H)
Tol
%
M
M
M
M
M
M
M
M
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
Q Min. SRF
(**MHz) Min.
(MHz)
40
40
40
40
40
40
40
40
40
40
45
50
50
50
50
45
45
45
40
40
40
45
50
50
50
50
50
50
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
380
360
350
320
300
280
250
200
180
165
150
125
85
80
75
65
45
36
30
28
22
20
16
15
13
11
10
9.5
8.5
7.5
6.5
6.0
5.5
5.4
4.75
4.35
4.00
3.70
3.40
2.80
2.55
2.35
2.00
1.50
1.20
R
DC
MAX
(
Ω
)
0.08
0.08
0.08
0.09
0.10
0.11
0.12
0.13
0.15
0.18
0.20
0.23
0.25
0.28
0.30
0.32
0.35
0.40
0.45
0.55
0.72
0.80
0.88
1.00
1.20
1.35
1.50
1.70
2.30
2.60
3.20
3.50
3.80
3.80
4.40
5.00
5.70
6.50
9.50
10.5
11.6
13.0
18.0
23.0
26.0
I
DC
I
N
(mA)
1150
1110
1110
1000
1000
950
900
875
815
740
700
655
630
595
575
555
530
500
470
425
370
350
335
315
285
270
255
240
205
195
185
175
165
160
150
140
130
120
100
95
90
85
75
65
60
ECM63T-R22
0.22 @25.2 MHz
ECM63T-R27
0.27 @25.2 MHz
ECM63T-R33
0.33 @25.2 MHz
ECM63T-R39
0.39 @25.2 MHz
ECM63T-R47
0.47 @25.2 MHz
ECM63T-R56
0.56 @25.2 MHz
ECM63T-R68
0.68 @25.2 MHz
ECM63T-R82
0.82 @25.2 MHz
ECM63T-1R0
1.0 @25.2 MHz
ECM63T-1R2
1.2 @7.96 MHz
ECM63T-1R5
1.5 @7.96 MHz
ECM63T-1R8
1.8 @7.96 MHz
ECM63T-2R2
2.2 @7.96 MHz
ECM63T-2R7
2.7 @7.96 MHz
ECM63T-3R3
3.3 @7.96 MHz
ECM63T-3R9
3.9 @7.96 MHz
ECM63T-4R7
4.7 @7.96 MHz
ECM63T-5R6
5.6 @7.96 MHz
ECM63T-6R8
6.8 @7.96 MHz
ECM63T-8R2
8.2 @7.96 MHz
ECM63T-100
10 @7.96 MHz
ECM63T-120
12 @2.52 MHz
ECM63T-150
15 @2.52 MHz
ECM63T-180
18 @2.52 MHz
ECM63T-220
22 @2.52 MHz
ECM63T-270
27 @2.52 MHz
ECM63T-330
33 @2.52 MHz
ECM63T-390
39 @2.52 MHz
ECM63T-470
47 @2.52 MHz
ECM63T-560
56 @2.52 MHz
ECM63T-680
68 @2.52 MHz
ECM63T-820
82 @2.52 MHz
ECM63T-101
100 @2.52 MHz
ECM63T-121
120 @ 0.796 MHz
ECM63T-151
150 @ 0.796 MHz
ECM63T-181
180 @ 0.796 MHz
ECM63T-221
220 @ 0.796 MHz
ECM63T-271
270 @ 0.796 MHz
ECM63T-331
330 @ 0.796 MHz
ECM63T-391
390 @ 0.796 MHz
ECM63T-471
470 @ 0.796 MHz
ECM63T-561
560 @ 0.796 MHz
ECM63T-681
680 @ 0.796 MHz
ECM63T-821
820 @ 0.796 MHz
ECM63T-102
1000 @ 0.796 MHz
** = Test
TOLERANCES ; K= 10%
Frequency as specified in ‘L’ column
ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK
Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk
Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to
discontinue any product or make design changes we believe necessary.
Issue 1
