DRAWING NO.
1
27-9010-CUST
REVISIONS
Description:
BNC male crimp dual ferrule for RG58/59
OFFICAL RELEASE
D
Part No:
Application:
Crimp Tool:
Impedance:
Frequency Range:
Material:
27-9010
For Cable RG58,RG59,RG59 PLENUM
24-9960P
50 Ohms
0-4 GHz
Body
Contact
Insulator
Brass Nickel plated
Phos Bronze Gold plated
Delrin
01
03-11-09
J
J
T
W
T
Thoma
s Chow
D
C
RoHS Compliance:
Technical Detail:
Crimp Sleeve Brass Nickel plated
Coupling Nut Zinc Nickel plated
Yes
Refer to Emerson Document P/N 27-0000
C
17.2
.677in
B
O
O
O
5.60
.220in
9.0
.354in
O
7.7
.303in
25
.975in
9.7
.382in
B
6.5
.256in
O
8.40
.331in
O
5.30
.209in
REF.
O
14.5 ( .571in )
17.1
.673in
O
9.0
.354in
CUSTOMER COPY
TOLERANCE UNLESS DRAWN BY
OTHERWISE SPECIFIED
JEAN.JIN
DECIMALS
X
mm
CHECKED BY
DATE
03-11-09
DATE
TITLE
A
O
6.40
.252in
O
7.2
.283in
O
8.40
.331in
Connectivity
Solutions
BNC MALE CRIMP DUAL FERRULE
FOR RG58/59
SHEET
1 OF 1
DRAWING NO.
SIZE
A
DIM OUTLINE
CONTROLLED DOCUMENT
27-9010-CUST
01
Apr29,09
X.X
X.XX
ANGLES
+
0.5
-
+
0.3
-
+
0.1
-
+
0.5
-
TERRY.W
THOMAS
U/M
03-11-09
APPROVED BY DATE
03-12-09
v
mm
P/N
Rev
Rel'd Date
THIS DRAWING WAS PRODUCED BY COMPUTER,
DO NOT SCALE DRAWING OR UPDATE MANUALLY.
27-9010-CUST
1
A
5
4
3
2
