Specification for release
Customer
:
Ordercode:
Description:
Package:
82402375
TVS Diode Array WE-TVS
SC70-6L
DATUM / DATE : 2010-01-27
A
Features:
•
ESD Protection for 5 Lines - unidirectional
•
Provide ESD Protection for each line to
IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
IEC 61000-4-4 (EFT) 35A (5/50ns)
IEC 61000-4-5 (Lightning) 6A (8/20µs)
•
Below 5V operating voltage: 2.5 - 3.3 - 4.2 - 5.0V
•
Array of surge rated equivalent TVS diodes
Mechanical Characteristics:
•
JEDEC SC70-6L Package
•
Molding compound flamability rating: UL94V-0
•
Packaging: Tape & Reel
B
Schematic and Pin Configuration:
6
5
4
1
2
3
C
Absolute Maximum Ratings:
Peak Pulse Current (tp = 8/20µs), pin 5
Peak Pulse Current (tp = 8/20µs), pin 1,3,4,6
ESD per IEC 61000-4-2 (Air / Contact)
Operating Temperature
Storage Temperature
Symbol
I
PP
I
PP
V
ESD
T
Op
T
Sto
Rating
3.5
6
16 / 10
-55 to +85
-20 to +60
Unit
A
A
kV
°
C
°
C
D
Electrical Characterisitcs:
Properties
Test Conditions
Value
min
V
RWM
V
BV
I
R
V
F
v
C
I
PP
=3.5A, tp=8/20µs, pin 5 to pin 2
Pin 1,3,4,5,6 to pin 2
I
BV
=1mA, pin 1,3,4,5,6 to pin 2
V
RWM
=5V, pin 1,3,4,5,6 to pin 2
I
F
= 15mA, pin 2 to pin 1,3,4,5,6
I
PP
=5A, tp=8/20µs, pin 1,3,4,6 to p.2
Value
typ
Value
max
5
Unit
V
V
6.0
2.5
0.6
0.8
6.8
6.2
8.5
13
17
1
µA
V
V
V
V
pF
v
Cl
C
IN
I
TLP
= 17A, pin 1,3,4,5,6 to pin 2
V
IO
=0V, f=1MHz, pin 1,3,4,5,6 to p.2
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Phone (+49) (0) 7942 - 945 - 0 · Fax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
PAGE 1 OF 5
Specification for release
Customer
:
Ordercode:
Description :
Package:
82402375
TVS Diode Array WE-TVS
SC70-6L
I
Tape:
K
I
Feeding Direction
Ø
D
E
F
Pin 1
J
A
B
C
D
E
F
G
H
I
J
K
C
2.25 REF
4.00 ± 0.10
8.00 ± 0.20
1.55 ± 0.05
4.00 ± 0.10
2.00 ± 0.05
1.75 ± 0.10
3.50 ± 0.05
2.4 REF
1.2 REF
0.30 ± 0.02
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
G
H
A
B
J
Reel:
a
b
c
d
178.0 ± 2.0
13.0 ± 0.8
10.0 ± 1.5
12.5 ± 2.0
mm
mm
mm
mm
b
a
165° to 180°
c
d
Quantity per Reel:
3000
General Release:
Customer
..................................................................................
..................................................................................
Date
Signature
Würth Elektronik
..................................................................................
..................................................................................
JB
Name
Version 1
Modification
2010-01-27
Checked
Approved
Date
This electronic component has been designed and developed for usage in general electronic equipment. Before incorporating this component into any equipment where higher safety
and reliability is especially required or if there is the possibility of direct damage or injury to human body, for example in the range of aerospace, aviation, nuclear control, submarine,
transportation, (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc, Würth Elektronik eiSos GmbH must be
informed before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic component which is used in electrical circuits
that require high safety and reliability functions or performance.
Würth Elektronik eiSos GmbH & Co. KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 · Germany · Phone (+49) (0) 7942 - 945 - 0 · Fax (+49) (0) 7942 - 945 - 400
PAGE 5 OF 5
http://www.we-online.com
