INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 860
1,8
Panel Mount, Shocksafe Specifications
5x20mm / 6.3x32mm Fuses
S t a n d a r d
53,7 + 0,5
0,5
4,8
4 + 0,2
M12,7x1,5
IEC 60127-6
UL 512
CSA C22.2. No.39
VDE Report
SEMKO
UL Recognized
CSA Certified
SEV
∅15
+ 0,3
Approvals
max. 7
12,5
6,5
VDE
11,7 -0,15
12,2 -0,13
Mounting
12,7 -0,1
12,7 -0,1
12.7mm diameter D-hole or double D-hole
Admissible torque on plastic hex nut is 1.2Nm
Solderable or 4.8mm quick connect-fits 0.5mm tab
IP 40 (IEC 60529)
PC2 (IEC 60127-6)
Panel alternatives
Terminals
Protection Class & Category
Cap / No. 865
1,6
6,5
1,8
Materials
Holder/Cap: Black Thermoplastic, UL 94V0
Metal Parts: Copper alloy, corrosion protected
Terminals: Solderable, tinned
Rated Voltage: 250V
Rated Current: 10A (VDE/SEMKO)
16A (CSA)
20A (UL)
Rated Power : 4.0W (VDE/SEMKO)
-40ºC to +85ºC (consider de-rating)
-40ºC/+85ºC/21 days (IEC 60068-2-1...3)
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 500Hz at 10g acceleration
≤
5mΩ
Electrical Data (23ºC)
For 5x20mm Fuses
10,2
∅9,1
+ 0,3
31 + 0,5
Temperature
Operating Temperature
Test
Climatic Test
Stock Conditions
Cap / No. 866
1,6
6,5
∅9,1
+ 0,3
1,8
Vibration Resistance
Contact Resistance
10,2
Impulse Voltage
25,6 + 0,6
4 kV, 50 Hz, 1 min., dry
> 10
3
MΩ (500 VDC, 1 min.)
235ºC, 2 sec. (Wave)
350ºC, 1 sec. (Soldering Iron)
350ºC, 5 sec. (IEC 60068-2-20)
Conductor - 2.5mm
2
For 6.3x32mm Fuses
Insulation Resistance
Solderability
Order Information
Packaging
Bulk (100 pcs.)
Holder
Cap, 5x20mm
Cap, 6.3x32mm
No. 860 0000 100
No. 865 0000 100
No. 866 0000 100
Soldering Heat Resistance
Minimum Cross Section
Marking
860, 250V, Approvals
5.3g (860) / 3.3g (865) / 2.5g (866)
Order Numbers
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
Unit Weight
Specifications are subject to change without notice
050816
