Bussmann
®
Class CC Fuseblocks
600 Volt, 30 Amps
Dimensional Data
1 POLE
BC
Series
Catalog Symbol:
BC Series
Class CC Fuseblocks
For use with Class CC Fuses (Bussmann LP-CC, KTK-R,
and FRQ-R)
Ampere Rating:
⁄Ω¡º to 30A
Voltage Rating:
600V
Withstand Rating:
200,000A RMS Sym.
Agency Information:
UL Listed, UL 512, Guide IZLT, File E14853
CSA Certified, C22.2 No. 39, Class 6225-01, File 47235
UL Flammability:
94VO
Materials:
Base - Thermoplastic
Clips - Bright tin-plated bronze
DIN-RAIL Adapters:
DRA-1 and DRA-2
Catalog Data
th o
e m O
Se BC me B
M n d SO
e
da m e L
d E
ta od r T
ul ep E
sh
ar la
ee
ce
t n fus m
o. e e
bl nt
10 o
ck is
24
1 .
(76.20mm + 0.38mm)
(21.03mm + 0.38mm)
3.000" + 0.015"
0.828" + 0.015"
0.360"
(9.14mm)
(5.08mm + 0.08mm)
0.200" + 0.003"
2 POLE
0.425"
(10.80mm)
(41.28mm + 0.38mm)
1.625" + 0.015"
0.765"
(19.43mm)
.169"
±
.210"
4.29mm
±
5.33mm
Typ. 2
3 POLE
0.425"
(10.80mm)
1.530"
(38.86mm)
Terminal Type
Amps
⁄Ω¡º
1
to
2
30
3
Screw
BC6031S
BC6032S
BC6033S
Screw with
Quick
Connect*
BC6031SQ
BC6032SQ
BC6033SQ
Pressure
Plate
BC6031P
BC6032P
BC6033P
Pressure
Plate w/
Quick
Connect*
BC6031PQ
BC6032PQ
BC6033PQ
(60.33mm + 0.38mm)
2.375" + 0.015"
.750"
(19.05mm)
Poles
Box
Lug
BC6031B
BC6032B
BC6033B
.172"
(4.37mm)
Typ. 2
ec
(5.08mm + 0.08mm)
0.200" + 0.003"
FUSEBLOCK LABEL
(EXAMPLE SHOWN)
R
Wire
Range
CU Only
BC6031S
REPLACES CC60030-18
Buss
®
#10-#14
#10-#14
#10-#14
#10-#14
#6-#14
(30.73mm + 0.38mm)
1.210" + 0.015"
30A
600V
BUSSMANN
COOPER INDUSTRIES
ST. LOUIS, MO 63178
MADE IN U.S.A.
75 C WIRE
200,000A RMS SYM
WITHSTAND RATING
* QUICK CONNECT RATED FOR 20A MAXIMUM.
CLASS CC
FUSES ONLY
CU ONLY
10-14
20 LB IN.
R
XXXX
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 Vac, 75-1500 Vdc). Refer to Data Sheet: 8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is
intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
9-18-02
SB02295
Form No. BC Series
Page 1 of 1
Data Sheet: 1105
