Technical Data
2036
Effective
August
2017
Supersedes
March
2009
S504
5
mm x
20
mm Time-delay
glass
tube fuses
Agency information
•
UL Recognized Card: (32 mA-3.15 A) Guide JDYX2, File
E19180
•
Semko Approval, 32 mA-6.3 A
•
VOE Approval, 32 mA-5 A
•
BSI Approval, 32 mA-6.3 A
•
IMQ Approval, 32 mA-6.3 A
•
MITI Approval, 1 A-6.3 A
Dimensions
Product features
•
•
•
•
•
Time delay, low breaking capacity
5 mm x 20 mm physical size
Glass tube, nickel-plated brass endcap construction
Optional axial leads are .032" x 1.5" copper tinned
Designed to IEC 60127-2 (50 mA - 6.3 A)
Drawing Not to Scale
2
1.
10
(,
-81
Ordering
•
Specify product code, option code and packaging code
Voltage
rop mV
S504-40mA
S504-50mA
S504-63mA
S504-80mA
S504-100mA
S504-125mA
S504-160mA
S504-200mA
S504-250mA
S504-315mA
S504-400mA
S504-500mA
S504-630mA
S504-800mA
S504-1A
S504-1.25A
S504-1.6A
S504-2A
S504-2.5A
S504-3.15A
S504-4A
S504-5A
S504-6.3A
•
1050
920
800
760
580
490
390
320
340
270
250
210
168
158
132
85
80
80
80
80
75
75
75
65
t
DC Cold Resistance (Measured at <10% of rated current)
Me
lting l'
t (l't was measured at listed interrupting rating and rated voltage)
°
c ambient temperature at rated current)
Maximum Voltage Drop (Voltage
Technical Data
2036
Effective
August
2017
S504
5 mm x 20 mm Time-delay glass tube fuses
OBSOLETE
OptionCode
V
I
I
Axial leads - coooer tinned wire with nickel plated brass overcaps
Description
OPTION
CODE
Packaging Code
BK
BK1
TR2
Description
PACKAGING
CODE
100 oieces of fuses oacked into
baq
1, 000 pieces of fuses packed into a
1, 500
of fuses oacked into taoe on a reel (19.05mm lead wire lenoth)
Life Support Policy: Eaton does not authorize the use of any of its products for use in life support devices or systems without the express written
approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly
used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
Eaton reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Eaton also
reserves the right to change or update, without notice, any technical information contained in this bulletin.
Eaton
Electronics Division
1000 Eaton Boulevard
Cleveland, OH 44122
United States
www.eaton.com/electronics
© 2017 Eaton
All Rights Reserved
Printed in USA
Publication No.
2036
August
2017
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
