Technical Data
2039
Effective
May
2017
Supersedes
October
2011
AGA
1/4"
x
5/8" Fast-acting
glass tube fuses
Agency information
•
UL Listed, Guide JDYX, File E19180 (AGA: 0 - 3 1/2A)
•
UL Recognized, Guide JDYX2, File E19180 (AGA: 12 - 30A)
Ordering
•
Specify packaging, product and option code
Product features
•
•
•
•
•
Fast-acting
1/4" x 5/8" (6.4 x 15.9mm) physical size
Glass tube, nickel-plated brass end cap construction
Optional axial leaded version available
UL Listed product meets standard 248-14
Rated Current
1
/
4
- 10A
Electrical characteristics
% of Amp Rating
Opening Time
100%
4 hours minimum
135%
60 minutes maximum
200%
120 seconds maximum
Part Number
(Amps)
1
AGA-/
10
1
AGA-/
4
1
AGA-/
2
3
AGA-/
4
AGA-1
1
AGA-1-/
2
AGA-2
1
AGA-2-/
2
AGA-3
AGA-5
AGA-6
AGA-7
1
AGA-7-/
2
AGA-10
AGA-15***
AGA-20***
AGA-25***
AGA-30***
Voltage Rating
Vac
250
250
250
250
250
250
250
250
250
125
125
125
125
125
32
32
32
32
AC Interrupting Rating* (Amps)
250Vac
125Vac
32Vac
35
10,000
-
35
10,000
-
35
10,000
-
35
10,000
-
35
10,000
-
100
10,000
-
100
200
-
100
200
-
100
200
-
-
1000
-
-
1000
1000
-
1000
1000
-
1000
1000
-
1000
1000
-
-
1000
-
-
1000
-
-
1000
-
-
1000
Typical DC ColdResistance ()**
Ω
Lower
Upper
6.186
8.370
0.649
0.879
0.223
0.301
0.116
0.157
0.088
0.118
0.056
0.076
0.038
0.052
0.027
0.036
0.022
0.030
0.013
0.017
0.011
0.015
0.008
0.011
0.008
0.010
0.006
0.008
0.003
0.004
0.002
0.003
0.001
0.002
0.001
0.002
* Interrupting Rating: Interrupting ratings has been measured at 70%-80% power factor.
** DC Cold Resistance (Measured at <10% of rated current)
*** UR Component Recognized at 125Vac 100A IR
Technical Data
2039
Effective
May
2017
AGA
1/4" x 5/8" Fast-acting glass tube fuses
Time-Current Characteristic Curves–Average Melt
CURRENT IN AMPS
Dimensions - mm (in)
15
20
2
3
1
10
5
30
TIME IN SECONDS
TIME IN SECONDS
CURRENT IN AMPS
Packaging Code
BK
BK8
Description
100 fuses packed into a cardboard carton
8000 fuses packed into a cardboard carton
Packaging Code
Option Code
B
Description
Board Washable - Hermetically sealed to withstand aqueous cleaning
Option Code
Life Support Policy: Eaton does not authorize the use of any of its products for use in life support devices or systems without the express written
approval of an officer of the Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly
used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in significant injury to the user.
Eaton reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of any products. Eaton also
reserves the right to change or update, without notice, any technical information contained in this bulletin.
Eaton
Electronics Division
1000 Eaton Boulevard
Cleveland, OH 44122
United States
www.eaton.com/electronics
© 2017 Eaton
All Rights Reserved
Printed in USA
Publication No. 2039
BU-SB111165
May
2017
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
