Technical Data 1011
Effective December 2015
Supersedes April 2014
BUSSMANN
SERIES
KTK 13⁄32˝ x 1-1⁄2˝ 600Vac fast-acting
supplemental fuses
Catalog symbol / color code:
•
Dimensions - in (mm):
KTK - Black (600Vac max)
Description:
Fast-acting, supplemental fuse.
For superior protection, Bussmann Division rec-
ommends upgrading to Low-Peak™ Class CC
fuses. See data sheet No. 1023.
0.41"
(10.3)
1.5"
(38.1)
Features
•
•
•
•
Color coded black for 600Vac voltage rating
Fast-acting for resistive loads
Melamine tube construction
Nickel-plated endcaps
Specifications:
Ratings
Interrupting rating
at rated voltage
Agency
information
UL
X
®
Typical applications
•
®
Fuse
amp range 600Vac
1/10 to 30 100kA
Control circuits
Lighting circuit protection
Meter circuits
CSA
X
•
•
600Vac
1/10 to 30A
Agency information
•
•
CE, RoHS compliant
UL Listed, Std. 248-14, Guide JDYX,
File E19180
CSA Certified: C22.2 No. 248.14,
Class 1422-01, File 53787, HRC-MISC
Recommended fuse blocks/fuse
holders:
Catalog
symbols
BMM
Description
Blocks
1-, 2- and 3-pole
modular blocks with
optional covers
1-, 2- and 3-pole
switch
1-, 2- and 3-pole
3-pole protection
module
3-pole holder
3-pole holder +
switch
1-pole holder
1-pole holder
2-Pole holder
1-pole holder
1-pole holder
1-pole holder
1-pole holder
2-pole holder
Data sheet
No.
10235
•
Catalog numbers (amps)
KTK-1/10
KTK-1/8
KTK-2/10
KTK-1/4
KTK-3/10
KTK-4/10
KTK-1/2
KTK-6/10
KTK-3/4
KTK-1
KTK-1-1/4
KTK-1-1/2
KTK-2
KTK-2-1/2
KTK-3
KTK-3-1/2
KTK-4
KTK-5
KTK-6
KTK-7
KTK-7-1/2
KTK-8
KTK-9
KTK-10
KTK-12
KTK-15
KTK-20
KTK-25
KTK-30
DIN-Rail holders / switches
CCP-_-30M
CHM
Optima NG
Optima
Optima
1157
3185
1109
1102
1103
Panel mount holders
HPM and HPM-D
HPC-D
2112
2109
2140
2114
2113
2108
2127
2126
Carton quantity
Amps
1/10 to 30
Qty.
10
HPS2
HPF HPF-C and
,
HPF-WT
HPS
HPG and HPD
In-line holders
HEB
HEX
Fuseclips
1A3400, 5956
and 5960
Fuse covers
CVR(I)-CCM(-QC)
PCB fuseclips
2132
Finger-safe fuse cover 10235
Technical Data 1011
Effective December 2015
KTK
600Vac fast-acting supplemental fuses
Time-current characteristic curves – average melt
:
6/10
3/4
1
1-1/2
2
2-1/2
3
4
5
6
7
8
20
10
15
25
30
100
Amp
rating
Amp
Rating
10
Time seconds
Time in Seconds
1
0.1
0.9
1
Current in Amps
Current in amps
