L-Series - UL489 Miniature Molded Case Circuit Breaker -
1 pole C-Trip /
DC
Rated
Current
0.2A
0.5A
1.0A
1.6A
2.0A
3.0A
4.0A
5.0A
6.0A
8.0A
10A
12A
13A
15A
16A
20A
25A
30A
32A
40A
50A
60A
63A
Type/
Cat. No.
DC1CU02L
DC1CU05L
DC1CU1L
DC1CU1.6L
DC1CU2L
DC1CU3L
DC1CU4L
DC1CU5L
DC1CU6L
DC1CU8L
DC1CU10L
DC1CU12L
DC1CU13L
DC1CU15L
DC1CU16L
DC1CU20L
DC1CU25L
DC1CU30L
DC1CU32L
DC1CU40L
DC1CU50L
DC1CU60L
DC1CU63L
C and D Trip, Less than 10A
120
60
40
20
Minutes
LISTED
E305318
10
8
6
4
2
1
40
20
10
5
Tripping time t
1
0.5
Seconds
0.05
0.1
One Pole
Standard Pack:
12
Weight:
1.7kg (3.74 lb.)
0.01
C
1
2
3
4
Multiple of Rated Current
D
5 6 7 8 9 10 12 14 16 20
1.05 1.3
C and D Trip, 10A and higher
7200
3600
2400
1200
Minutes
Tripping time t
DC Version Current/ Voltage Rating
0.2-63A/125/250VDC
Calibration Temperature
Operating Temperature
Storage Temperature
Terminal Size Acceptability:
Solid Wire
Stranded Wire
Terminal Torque
Terminal Protection Degree
Electrical Life
Mechanical Life
Wire Connection
18 AWG -10 AWG
18 AWG -6 AWG
2.8 Nm (25 lb-in.)
IP20
6000 cycles on/off
100000 cycles on/off
copper wire only 60/75°C
Seconds
40°C (104°F)
-25° to 60°C (-13° to 140°F)
-25° to 75°C (-13° to 167°F)
600
480
360
240
120
60
40
20
10
5
1
0.5
0.05
0.1
0.01
14.5mm (0.57 in.)
C
1
2
3
4
Multiple of Rated Current
D
5 6 7 8 9 10 12 14 16 20
1.05 1.3
109mm (4.29 in.)
45mm (1.77 in.)
69mm (2.72 in.)
DC
- short CirCuit interruptinG ratinG
No.
Poles
1
Type
DC
0.2-32A
10kA@125V
6.5mm
(0.26 in.)
17.5mm (0.69 in.)
44mm (1.73 in.)
60mm (2.36 in.)
For ring tongue terminal version, replace "U" with "R" in part number. For example
DC1CR20L
instead of
DC1CU20L.
