D1213A-04MR
4 CHANNEL LOW CAPACITANCE TVS DIODE ARRAY
Features
ADVANCE INFORMATION
•
•
•
•
•
•
•
IEC 61000-4-2 (ESD): Air ±15kV, Contact ±8kV
4 Channels of ESD Protection
Low Channel Input Capacitance of 0.85pF Typical
Typically Used at High Speed Ports such as USB 2.0,
IEEE1394, Serial ATA, DVI, HDMI, PCI
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
Case: MSOP-10
Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Copper leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Weight: 0.026 grams (approximate)
MSOP-10
Ch1
1
2
3
4
5
10
9
8
7
6
NC
Ch4
V
N
NC
Ch3
Pin#
1, 4, 6, 9
2, 5, 7, 10
8
3
Description
Inputs
No Connection
V
N
, Ground
Vp, Power
NC
V
P
Ch2
NC
Pin Description
Top View
Device Schematic
Ordering Information
(Note 4)
Part Number
D1213A-04MR-13
Notes:
Case
MSOP-10
Packaging
2500/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
TV13
YYWW
TV13 = Product Type Marking Code
YYWW = Date Code Marking
YY = Last Two Digits of Year (ex: 12 = 2012)
WW = Week Code (01 ~ 53)
D1213A-04MR
Document number: DS35595 Rev. 6 - 2
1 of 5
www.diodes.com
November 2012
© Diodes Incorporated
D1213A-04MR
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
ADVANCE INFORMATION
Characteristic
Operating Supply Voltage
DC Voltage at any Channel Input
Peak Pulse Current
ESD Protection – Contact Discharge
ESD Protection – Air Discharge
Symbol
V
P
- V
N
-
I
PP
Value
6.0
(V
N
– 0.5) to (V
P
+ 0.5)
5
±8
±15
Unit
V
V
A
kV
kV
Conditions
-
-
8/20
μs,
Per Fig. 3
Standard IEC 61000-4-2
Standard IEC 61000-4-2
V
ESD_Contact
V
ESD_Air
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
500
250
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Operating Supply Voltage
Operating Supply Current (Note 6)
Channel Leakage Current (Note 6)
Reverse breakdown voltage
Clamping Voltage, Positive Transients
Clamping Voltage, Negative Transients
Forward Voltage for Top Diode
Forward Voltage for Bottom Diode
Dynamic Resistance
Channel Input Capacitance
Notes:
Symbol
V
P
I
P
I
R
V
BR
V
CL1
V
CL2
V
FD1
V
FD2
R
DYN
C
T
Min
-
-
-
6.0
-
-
0.60
0.60
-
-
Typ
3.3
-
0.1
-
10.0
-1.7
0.80
0.80
0.9
0.85
Max
5.5
8.0
1.0
-
-
-
0.95
0.95
-
1.2
Unit
V
μA
μA
V
V
V
V
V
Ω
pF
Test Conditions
−
(V
P
– V
N
) = 3.3V
V
P
= 5V, V
N
= 0V
I
R
= 1mA
I
PP
= 1A (Note 7)
I
PP
= -1A (Note 7)
I
F
= 8mA, any channel to V
P
I
F
= 8mA, V
N
to and channel
I
PP
= 1A (Note 7)
V
IN
= 1.65V, V
P
= 3.3V,
V
N
= 0V, f = 1MHz
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
7. Clamping voltage value is based on an 8x20μs peak pulse current (I
pp
) waveform.
8. Measured from any channel to V
N
9. Measured from V
P
to V
N
.
10. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
following URL: http://www.diodes.com/destools/appnote_dnote.html.
D1213A-04MR
Document number: DS35595 Rev. 6 - 2
2 of 5
www.diodes.com
November 2012
© Diodes Incorporated
D1213A-04MR
600
550
100
Note 5
ADVANCE INFORMATION
450
400
350
300
250
200
150
100
50
0
0
25
50
75
100
125
150
T
A
, AMBIENT TEMPERATURE (
°
C)
Figure 1 Power Derating Curve
175
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
P
D
, POWER DISSIPATION (mW)
500
75
50
25
0
0
25
50
75
100 125 150 175
T
A
, AMBIENT TEMPERATURE (°C)
Figure 2 Pulse Derating Curve
200
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
1,000
Note 9
I
PP
, PEAK PULSE CURRENT (%I
pp
)
100
100
10
T
A
= 150°C
1
T
A
= 125°C
50
0.1
T
A
= 85°C
T
A
= 25°C
0.01
T
A
= -55°C
0
0
20
40
t, TIME (
μ
s)
Figure 3 Pulse Waveform
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
10,000
Note 9
60
0.001
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Figure 4 Typical Forward Characteristics
2.0
f = 1MHz
Note 8
1,000
C
T
, TOTAL CAPACITANCE (pF)
1.5
100
T
A
= 150°C
T
A
= 125°C
T
A
= 85°C
1.0
10
T
A
= -55°C
T
A
= 25°C
0.5
1
0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Figure 5 Typical Reverse Characteristics
1.0
1.5
2.0
2.5
3.0 3.5
V
R
, REVERSE VOLTAGE (V)
Figure 6 Typical Total Capacitance vs. Reverse Voltage
0
0
0.5
D1213A-04MR
Document number: DS35595 Rev. 6 - 2
3 of 5
www.diodes.com
November 2012
© Diodes Incorporated
D1213A-04MR
Package Outline Dimensions
ADVANCE INFORMATION
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
E
GAUGE PLANE
L
a
DETAIL A
D
e
E3
A2
A1
b
A
c
A3
E1
DETAIL A
MSOP-10
Dim Min Max Typ
a
8°
4°
0°
A
-
1.10
-
A1
0.05 0.15 0.10
A2
0.75 0.95 0.86
A3
0.29 0.49 0.39
b
0.17 0.33 0.20
c
0.08 0.23 0.15
D
2.90 3.10 3.00
e
-
-
0.50
E
4.70 5.10 4.90
E1
2.90 3.10 3.00
E3
2.85 3.05 2.95
L
0.40 0.80 0.60
All Dimensions in mm
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
X
Y1
C
Y
Dimensions
C
X
Y
Y1
Value (in mm)
5.300
0.300
1.350
0.500
D1213A-04MR
Document number: DS35595 Rev. 6 - 2
4 of 5
www.diodes.com
November 2012
© Diodes Incorporated
D1213A-04MR
ADVANCE INFORMATION
